2N IP Verso Security Bundle with Relay, Tamper, I/O, 01975-001
Description
2N IP Verso Security Bundle
The 2N IP Verso Security Bundle packages the three modules that protect a Verso entrance against lock tampering: a security relay, a tamper switch and an I/O module. 2N designed it for attacks on low-power locks, where an intruder reaches the wires between intercom and lock, for example to open a door with a 12 V battery. The relay sits between the intercom and the lock, the tamper switch signals when the frame is opened, and the I/O module lets the intercom run follow-up actions such as sending a photo.
Key Specifications
| Part number | 01975-001 |
| Contents | Security relay (01386-001), tamper switch (01260-001), I/O module (01257-001) |
| Security relay switching | NO/NC contact, 30 V / 1 A AC/DC |
| Relay switched output | 8 to 12 V DC at up to 400 mA when powered from the device |
| Tamper switch | Two switches that open when the front frame is removed |
| I/O module | 2 relay outputs (30 V / 1 A), 2 inputs, tamper input |
| Fits | 2N IP Verso 2.0, 2N LTE Verso, original 2N IP Verso |
| Warranty | 5 years (per 2N) |
| 2N part number | 9155198SET |
Full specifications are listed in the Detailed Specifications tab.
What Each Part Does
- Security relay: goes between the intercom or reader and the electric lock, so the lock is only released by a valid code from the 2N device.
- Tamper switch: detects opening of the frame and, together with an I/O, OSDP or Wiegand module, raises an alarm through the automation interface.
- I/O module: adds extra inputs and relays so the intercom can, for example, take a photo and notify a security service when it is opened without authorization.
2N states the individual components can also be ordered separately.
Compatible Products
2N lists the bundle for these intercoms, available at Affinitech Store:
- 2N IP Verso 2.0 Main Unit with Camera and 1 Button, Nickel (02907-001)
- 2N IP Verso 2.0 Main Unit with Camera, Black (02908-001)
- 2N IP Verso 2.0 Audio-Only Main Unit, Nickel (03482-001)
- 2N IP Verso 2.0 Audio-Only Main Unit, Black (03483-001)
- 2N IP Verso Main Unit without Camera (01271-001)
- 2N IP Verso Main Unit without Camera, Black (01272-001)
- 2N IP Verso Main Unit with Camera (01273-001)
- 2N IP Verso Main Unit with Camera, Black (01274-001)
- 2N LTE Verso Intercom Main Unit with Camera, Black (01791-001)
- 2N LTE Verso Intercom Main Unit with Camera, Nickel (01792-001)
2N files the original 2N IP Verso under its discontinued products.
Related Products
Other 2N IP Verso parts: 2N IP Verso Wedge Backplate for 2 Modules (01940-001) and 2N IP Verso 125 kHz RFID Card Reader Module (02140-001).
Explore More
- Browse all Access Control products at Affinitech Store
- See Network Door Stations and Intercoms
Frequently Asked Questions About 2N IP Verso Security Bundle
What is in the 2N IP Verso Security Bundle?
A security relay (01386-001), a tamper switch (01260-001) and an I/O module (01257-001).
What threat does it address?
Attacks on low-power locks, where someone reaches the cable between intercom and lock and opens the door with a battery.
Which intercoms does it fit?
2N lists the 2N IP Verso 2.0, the 2N LTE Verso and the original 2N IP Verso.
Does the tamper switch work on its own?
No. 2N says it is not bus-connected and works together with an I/O, OSDP or Wiegand module.
What can the security relay switch?
A NO/NC contact rated 30 V / 1 A AC/DC, plus a switched 8 to 12 V DC output at up to 400 mA from the device.
What warranty does 2N give?
2N states a 5-year warranty on the product page.
Can I buy the parts separately?
2N says the bundle components may also be ordered individually.
Detailed Specifications
2N IP Verso Security Bundle Specifications
| Specification | Details |
|---|---|
| Product | |
| Name | 2N IP Verso Security Bundle |
| Part number | 01975-001 |
| Type | Security set: security relay, tamper switch, I/O module |
| Key Specifications | |
| Contents | Security relay (01386-001), tamper switch (01260-001), I/O module (01257-001) |
| Security relay switching | NO/NC contact, 30 V / 1 A AC/DC |
| Relay switched output | 8 to 12 V DC at up to 400 mA when powered from the device |
| Tamper switch | Two switches that open when the front frame is removed |
| I/O module | 2 relay outputs (30 V / 1 A), 2 inputs, tamper input |
| Fits | 2N IP Verso 2.0, 2N LTE Verso, original 2N IP Verso |
| Warranty | 5 years (per 2N) |
| 2N part number | 9155198SET |
| Security relay part number | 9159010 (01386-001) |
| Tamper switch part number | 9155038 (01260-001) |
| I/O module part number | 9155034 (01257-001) |
| I/O inputs | IN1/IN2, passive or active, -30 V to +30 V DC |
| Security relay size and weight | 66.5 x 32.5 x 20.5 mm, 24 g |
| Compatibility | |
| Fits | 2N IP Verso 2.0, 2N LTE Verso, 2N IP Verso (original) |
| Tamper switch requires | An I/O, OSDP or Wiegand module (the I/O module is included) |
| Parts Included | |
| Contents | Security relay (01386-001), tamper switch (01260-001) and I/O module (01257-001) |
| Shipping | |
| Shipping weight | 0.49 lb |
| Shipping dimensions (package) | 2.76 x 5.31 x 9.45 in (W x D x H) |
| EAN / UPC | 8595159515632 |
| Warranty | |
| Warranty | 5 years (2N) |
