2N Clip 2wire-IP 4.3-Inch Video Indoor Station, 03448-001
Description
2N Clip 2wire-IP Retrofit Video Indoor Station – 4.3-Inch
The 2N Clip 2wire-IP (03448-001) is a 4.3-inch IP video indoor station that connects directly to existing 2-wire cabling, so buildings can move to IP video without re-wiring. It talks to 2N IP intercoms through a 2N Clip 2wire-IP Switch (03450-001), which our product data lists as required for the network connection, and it is powered over the same pair.
Key Specifications
| Display | 4.3-inch colour, 480 x 272 px (2N product page) |
| Controls | 3 capacitive buttons |
| Video codec | H.264, up to 15 fps |
| Audio | Integrated microphone and speaker |
| Audio codecs | G.711a/u, G.722, G.729, L16/16 kHz |
| Induction loop | Not included (loop version is a separate order number) |
| Interface | 2wire-IP, 10 Mbit; 1 pair Cat3 or higher, 24 AWG |
| Power | 2wire-IP powered, 48 V DC, 200 mA |
| Signalling | SIP over UDP, TCP and TLS |
| Doorbell input | Normally open contact, 12 V / 20 mA DC |
| Dimensions (W x H x D) | 4.88 x 5.91 x 1.10 in |
| Warranty | 5 years |
Full specifications are listed in the Detailed Specifications tab.
Why Choose the 2N Clip 2wire-IP?
- Reuses legacy 2-wire cabling: one Cat3 or better pair, 24 AWG
- Upgrades a building to IP video with H.264 video on a 4.3-inch screen
- Powered over 2wire-IP at 48 V DC, 200 mA
- Three clearly visible capacitive buttons, with an optional tactile sticker for visually impaired users
- Induction loop version available under a separate order number
- Doorbell button can connect directly to the unit
- SIP over UDP, TCP or TLS with remote management
- Five-year warranty stated by 2N
Retrofit Without Re-Wiring
2N designed the Clip 2wire-IP for projects with legacy 2-wire infrastructure. The station connects to the existing cable (2N recommends one pair of Cat3 or better, 24 AWG, and advises checking the condition of old cabling first), and installation consists of drilling two screws, connecting the wires and clipping the unit to the wall.
The 2wire-IP Switch
Network access comes from the 2N Clip 2wire-IP Switch (03450-001), listed by 2N as an accessory and in our product data as required. Each switch has six powered 2wire-IP ports, so one switch can serve six indoor stations, and switches can be chained to cover more floors. The switch needs its own 48 V DC / 1.92 A supply, such as the 2N power supply 03479-001.
Video, Audio and Signalling
The station plays H.264 video at 480 x 272 at up to 15 fps, with audio in G.711a/u, G.722, G.729 and L16/16 kHz. Signalling is SIP over UDP, TCP or TLS. The induction loop is optional; order 03449-001 for the version with a built-in loop.
Power and Environment
Power consumption in the 2N manual ranges from 1.2 W in stand-by with the display off to 4.4 W during calls with audio (6.4 W with the induction loop). Operating temperature is 32 °F to 122 °F at 10% to 90% non-condensing humidity.
Typical Applications
- Older apartment buildings with existing 2-wire intercom cabling
- Hotels, student housing and care homes being upgraded to IP
- Residential retrofit projects where new cable is costly
- Buildings adding 2N IP Verso 2.0 or 2N Access Unit 2.0 entrances
Compatible Accessories
Accessories for the 2N Clip 2wire-IP. These items are not yet listed at Affinitech Store, so they are shown as text; contact us for availability:
- 2N Clip 2wire-IP Switch (03450-001), required for the network connection (new listing; link will be added)
- 2N power supply for the 2N Clip 2wire-IP Switch (03479-001)
- 2N Clip Desk Stand (02905-001) and 2N Clip Single-Gang Box installation plate (02906-001)
- 2wire-IP NVT PhyLink adapter, 1 pc (03520-001) or 6 pcs (02319-001)
- Entrances listed by 2N as compatible and complementary: 2N IP Verso 2.0 and 2N Access Unit 2.0
Compare 2N Indoor Stations and Answering Units
| Model | Key spec | Type | Best for |
|---|---|---|---|
| 2N Indoor Talk | Audio only, 7 capacitive buttons | Wired audio answering unit | Apartments and homes that need voice-only entry calls |
| 2N Indoor Compact | 4.3-inch colour display, 480 x 272 | Wired video answering unit | Residential projects that need a compact video screen |
| 2N Indoor View | 7-inch touchscreen, 1024 x 600 | Wired video answering unit | Premium residences that want a larger touch interface |
| 2N Indoor View Wi-Fi | 7-inch touchscreen, 2.4/5 GHz Wi-Fi | Wi-Fi or Ethernet video answering unit | Retrofits where running a network cable is hard |
| 2N Clip (Ethernet) | 4.3-inch colour display, 480 x 272, PoE | Wired video indoor station | Mid-range IP intercom projects |
| 2N Clip 2wire-IP (this unit) | 480 x 272 display over 2-wire-IP cabling | Retrofit video indoor station | Upgrading buildings that already have 2-wire cabling |
| 2N IP Phone D7A | 7-inch Android touchscreen, 16 SIP accounts | Desk IP phone | Reception desks that answer intercom calls |
The version with a built-in induction loop is order number 03449-001.
Explore More
- Browse all Network Door Stations and Intercoms at Affinitech Store
- See the full Access Control collection
Frequently Asked Questions About 2N Clip 2wire-IP
What is the 2N Clip 2wire-IP?
A 4.3-inch IP video indoor station for retrofit projects that connects directly to existing 2-wire cabling.
Do I need an extra switch?
Our product data states the 2N Clip 2wire-IP Switch (03450-001) is required for the network connection. 2N lists it as an accessory.
What cable does it use?
One pair of Cat3 or higher, 24 AWG. 2N advises verifying the condition of legacy cabling before use.
How is it powered?
Over the 2wire-IP connection at 48 V DC, 200 mA.
Does this version have an induction loop?
No. The loop version is 03449-001.
Which video and audio formats are supported?
H.264 video at up to 15 fps and G.711a/u, G.722, G.729 and L16/16 kHz audio, with SIP over UDP, TCP or TLS.
Can I connect a doorbell button?
Yes, directly to the unit. The input is a normally open contact rated 12 V / 20 mA DC.
How is it installed?
Drill two screws, connect the legacy wires and clip the unit to the wall.
How big is it?
4.88 x 5.91 x 1.10 in (W x H x D) per the 2N product page.
What warranty does it have?
2N states a 5-year warranty on the product page.
Is there a loop or non-loop version?
The version with a built-in induction loop is order number 03449-001.
Detailed Specifications
2N Clip 2wire-IP Specifications
| Specification | Details |
|---|---|
| Product | |
| Model | 2N Clip 2wire-IP |
| Order number | 03448-001 |
| 2N part number | 9138521 |
| Type | Indoor IP video station for legacy 2-wire cabling |
| Required accessory (reseller product data) | 2N Clip 2wire-IP Switch, 03450-001 |
| Power | |
| Supply | 2wire-IP powered, 48 V DC, 200 mA |
| Consumption, stand-by, display off (2N manual) | 1.2 W |
| Consumption, stand-by, display on | 2.0 W |
| Consumption, calls without audio | 2.4 W |
| Consumption, calls with audio | 4.4 W |
| Consumption, calls with induction loop | 6.4 W |
| User Interface | |
| Controls | 3 capacitive buttons; press and hold RESET for factory settings |
| Display | 4.3-inch colour, 480 x 272 px (2N product page); the 2N manual lists a 4-inch, 480 x 272 px display |
| Audio | |
| Microphone | Integrated |
| Speaker | Integrated, 2 W / 8 Ω (2N product page); 3 W (2N manual) |
| Induction loop | Not included on this version |
| Codecs | G.711a/u, G.722, G.729, L16/16 kHz (PCMU, PCMA, G.729, G.722, L16/16 kHz in the manual) |
| Video and Signalling | |
| Video codec | H.264, 480 x 272 px, up to 15 fps |
| Video protocols | RTP, RTSP, HTTP |
| Signalling | SIP over UDP, TCP, TLS |
| Audio protocol | RTP |
| Interface | |
| Network | 2wire-IP, 10 Mbit |
| Recommended cabling | One pair of Cat3 or higher, 24 AWG (single-core) |
| Doorbell Input | |
| Input type | Switching contact (button or relay) |
| Contact type | Normally open (NO) |
| Parameters | 12 V / 20 mA DC |
| Mechanical and Environmental | |
| Dimensions (W x H x D) | 4.88 x 5.91 x 1.10 in (124 x 150 x 26 mm in the 2N manual) |
| Weight | 0.52 lb (2N product page); 295 g main unit (2N manual) |
| Mounting | Clipped to the wall on its holder; US single-gang plate 02906-001 and desk stand 02905-001 sold separately |
| Operating temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Relative humidity | 10% to 90%, non-condensing |
| Storage temperature | -4 °F to 158 °F (-20 °C to 70 °C) |
| Recommended altitude | 0 to 6,500 ft |
| Compatibility | |
| Complementary products (2N) | 2N IP Verso 2.0, 2N Access Unit 2.0, My2N app and My2N Management Platform |
| Shipping | |
| Shipping weight | 0.82 lb |
| Shipping dimensions (package) | 6.54 x 5.51 x 1.77 in |
| EAN / UPC | 8595159522913 |
| Warranty | |
| Warranty | 5 years (terms at 2n.com/warranty) |
