2N Indoor Compact White 4.3-Inch Video Answering Unit, 01936-001

2N Indoor Compact Video Answering Unit – White, 4.3-Inch Display

The white 2N Indoor Compact (01936-001) gives apartments and homes a compact video answering unit with a 4.3-inch colour screen, HD audio and a glass front in a light finish. It connects to 2N IP intercoms through a single network cable, can take its power from PoE, and is configured through a built-in web interface.

Key Specifications

Full specifications are listed in the Detailed Specifications tab.

Why Choose the 2N Indoor Compact?

• Compact 4.3-inch colour display (480 x 272) for seeing who is at the door
• HD-quality audio through a 2 W / 8 Ω speaker and integrated microphone
• Seven capacitive buttons with RGB LED backlighting
• Single UTP cable installation with PoE 802.3af, or a 12 V DC adapter
• Induction loop output for hearing-aid users
• Doorbell input for a local push button
• Flush, surface or desk-stand mounting using separate 2N accessories
• 2N lists IP Style, IP Verso 2.0, IP Force and IP Verso as suitable intercoms

Video at the Door, Sized for the Home

The White Indoor Compact shows H.264 video from the intercom on a 4.3-inch colour display with 480 x 272 resolution. It is designed for the residential market, where a small screen near the entrance is enough to see and talk to a visitor.

Audio and Accessibility

A 2 W / 8 Ω speaker and an integrated microphone support G.711a/u, G.722, G.729 and L16/16 kHz audio. An induction loop output rated at 600 mV RMS helps hearing-aid users, and the doorbell input accepts a normally open button or relay contact up to 50 V / 5 mA DC.

Power and Network

Connect a single 10/100BaseT cable (Cat5e or higher) and power the unit with PoE 802.3af, or use a 12 V DC adapter (12 V / 1 A recommended). Reverse polarity protection is included, and consumption is 12 W.

Mounting Options

Per the 2N manual, the unit mounts flush in a 103 mm hole cut 50 mm deep, on a wall with the 2N wall mounting box (which tilts the display by a 12% slope), or in a desk stand. Mounting accessories are sold separately.

Typical Applications

• Apartments and condominiums with 2N IP intercoms downstairs
• Single-family homes
• Residential developments needing a low-cost video answering unit
• Home offices that want a door-station screen at the desk

Compatible Accessories

Installation accessories for the 2N Indoor Compact. Linked items are available at Affinitech Store; contact us for the others:

• 2N Indoor Flush Box (01700-001) for flush installation
• 2N Indoor Surface Box (02320-001) for wall mounting
• 2N Indoor Desk Stand (02039-001) for tabletop use
• Compatible 2N intercoms listed by 2N: 2N IP Style and 2N IP Verso 2.0; 2N IP Force and 2N IP Verso (generation 1) are also listed, although 2N shows them among its discontinued products

Compare 2N Indoor Stations and Answering Units

Need black? See the 2N Indoor Compact in black (01935-001).

Explore More

• Browse all Network Door Stations and Intercoms at Affinitech Store
• See the full Access Control collection

Frequently Asked Questions About 2N Indoor Compact

How large is the display on the 2N Indoor Compact?

It has a 4.3-inch colour display with 480 x 272 pixel resolution.

What video codec does it use?

H.264 for the video stream. Audio codecs are G.711a/u, G.722, G.729 and L16/16 kHz.

How is the white 2N Indoor Compact powered?

By PoE IEEE 802.3af or a 12 V DC adapter; 2N recommends 12 V / 1 A. Consumption is 12 W and reverse polarity protection is included.

What network connection does it need?

A single 10/100BaseT RJ-45 connection. 2N recommends Cat5e or higher cabling.

Does it support hearing aids?

Yes, through an induction loop output rated at 600 mV RMS.

Can I connect an external doorbell button?

Yes. The input takes a normally open contact (button or relay) rated up to 50 V / 5 mA DC.

How is it mounted?

Flush in a 103 mm hole 50 mm deep, on a wall with the wall mounting box, or in a desk stand. The mounting accessories are not included.

What are its dimensions and weight?

5.98 x 6.02 x 1.97 in (W x H x D) and 0.853 lb, per 2N.

What temperature range is supported?

Operation from 32 °F to 122 °F, 10% to 90% relative humidity non-condensing; storage from -4 °F to 158 °F.

Which 2N intercoms can it be used with?

2N lists 2N IP Style, 2N IP Verso 2.0, 2N IP Force and 2N IP Verso as suitable products.

Does it come in another color?

Yes. The black version is the 2N Indoor Compact black (01935-001), also available at Affinitech Store.
