2N Access Unit QR Code Reader, Nickel, 03089-001

2N Access Unit QR – QR Code Access Reader for Visitors and Temporary Access

The 2N Access Unit QR (03089-001) is a stand-alone QR-code access reader that opens doors when a phone shows a QR code, with a built-in door controller. 2N positions it for visitors and temporary access: no card has to be issued or collected, and codes can be sent in advance. It comes as a two-module unit in nickel with one empty module position for expansion, and it works with the 2N IP Verso frame and mounting range.

Key Specifications

Full specifications are listed in the Detailed Specifications tab.

Why Choose the 2N Access Unit QR?

• Opens doors from a QR code on a phone, so visitors do not need a card
• QR codes can be colored or carry an image, and versions 1 to 40 are supported
• Built-in controller for a lock, exit button and door contact
• Supplied as a two-module unit with one free module position for expansion
• Works with 2N IP Verso accessory frames and boxes, according to 2N product data
• IP54 cover and IK08 impact rating with -40 °C to 60 °C operation
• PoE or 12 V DC power with gigabit-capable LAN
• 5-year warranty stated by 2N

Frictionless Visitor Entry

2N pitches QR access as more secure than a shared PIN and more sustainable than printed or plastic cards. A visitor, contractor or delivery person receives a QR code on a phone, shows it to the reader and the door opens. Temporary access ends on its own, which cuts the administration of returning and deactivating credentials.

What the Reader Accepts

The reader handles static QR codes containing 4 to 15 digits with decimal and hexadecimal characters, in every QR version from 1 to 40. The code itself can be colored or contain an image, so branded invitations work.

Controller and Door Wiring

The unit includes the controller. It offers a passive NO/NC switch rated 30 V, 1 A AC/DC, an active 8-12 V output and one input that works in passive or active mode, and an optional tamper switch extension module is available. A single Ethernet cable can carry both data and PoE power.

Frames and Mounting

The two-module frame measures 107 x 234 x 28 mm for surface mounting and 130 x 257 x 5 mm for flush mounting, and the flush box needs a 108 x 238 x 45 mm opening. 2N product data states the unit is compatible with 2N IP Verso accessory items and frames; 2N's own page lists the Access Unit 2.0 as the suitable product, so confirm the frame choice before ordering.

Typical Applications

• Visitor and guest entrances
• Meeting rooms and shared offices
• Elevator and floor access with temporary codes
• Contractor and delivery access
• Short-stay residential properties

Compatible Accessories

Compatible accessories for the 2N Access Unit QR, available at Affinitech Store:

• 2N IP Verso 2-Module Surface Frame, Nickel
• 2N IP Verso 2-Module Surface Frame, Black
• 2N IP Verso 2-Module Flush Frame, Nickel
• 2N IP Verso 2-Module Flush Frame, Black
• 2N IP Verso 2-Module Flush Box
• 2N IP Verso 2-Module Backplate
• 2N Security Relay
• 2N Magnetic Door Contact
• 15 W 1-Port PoE Midspan (T8120)

Compare 2N Access Unit Readers

Explore More

• Browse all Access Control Readers at Affinitech Store
• See the full Access Control collection
• See Network Door Stations and Intercoms

Frequently Asked Questions About 2N Access Unit QR

What is the 2N Access Unit QR?

It is a stand-alone QR-code access reader with a built-in controller, order number 03089-001.

What kind of QR codes does it read?

Static QR codes holding 4 to 15 digits (decimal and hexadecimal characters), all versions from 1 to 40. The code can be colored or contain an image.

Is it meant for visitors?

Yes. 2N describes it as aimed at visitors and temporary access, with less admin than cards.

Does it need a separate controller?

No. It has a passive NO/NC switch, an active 8-12 V output and an input, so it can run a door on its own.

How is it powered?

By PoE (IEEE 802.3af, 12.95 W max) or 12 V / 1 A DC.

What are the environmental ratings?

IP54 and IK08 cover rating, -40 °C to 60 °C operation and 10 to 95 percent humidity, non-condensing.

How many modules does it have?

It is supplied as a two-module unit with one empty module position, according to 2N product data.

Can I add other modules?

2N product data says it works with 2N IP Verso accessories. 2N lists the Access Unit 2.0 as the suitable product on its page, so verify module and frame choices before ordering.

Is there a tamper switch?

An optional tamper switch is available as an extension module; it is not built in.

What warranty does it have?

2N states a 5-year warranty on this product.
