Lenel LNL-M2210 PoE Intelligent Single Door Controller

Lenel LNL-M2210 PoE Intelligent Single Door Controller for OnGuard

The Lenel LNL-M2210 Intelligent Single Door Controller is an M-Series edge controller that runs one opening with one or two readers and powers itself over the network cable with PoE or PoE+. It stores up to 240,000 cardholders and a 500,000-event log on board, keeps making access decisions if the link to the OnGuard server drops, and talks to OnGuard over TLS 1.2/1.3. It suits offices, classrooms, IDF rooms and remote doors where a single network drop is easier than a home-run to a panel.

Key Specifications

Full specifications are listed in the Detailed Specifications tab.

Why Choose the Lenel LNL-M2210?

• Powered by PoE or PoE+, so one network cable powers the controller and its readers
• 240,000 cardholders and a 500,000-event log stored on the board
• Keeps controlling the door if the OnGuard server connection is lost
• TLS 1.2/1.3 to OnGuard and AES-256 to LenelS2 Series 3 modules, with an optional data-at-rest encryption setting
• Supports Wiegand, clock and data, OSDP RS-485, keypad, LCD and biometric readers
• Up to 600 mA of 12 VDC reader power
• Supports PIV, CAC and TWIC credentials plus proximity, iCLASS, MIFARE and DESFire cards
• Compact board: 5.5 x 2.75 x 0.96 in. without bracket

PoE Power and Simple Installation

The LNL-M2210 takes power from an 802.3af PoE (12.95 W) or 802.3at PoE+ (25 W) switch port, or from a local 12 VDC supply. On PoE it provides 12 VDC at 625 mA for readers and auxiliary devices; on PoE+ or local 12 VDC that rises to 1.25 A. Reader port power is 12 VDC at up to 600 mA.

Readers and Credentials

Reader port 1 accepts TTL, F/2F or 2-wire RS-485 readers, including OSDP readers; reader port 2 accepts TTL or F/2F. Use one reader per side of the door for in/out control, or a keypad or biometric reader for two-factor entry. LenelS2 lists support for PIV, CAC and TWIC cards as well as magnetic stripe, proximity, iCLASS, MIFARE and DESFire credentials.

Local Decisions and Event Storage

The controller holds up to 240,000 cardholders in 6 MB of flash and keeps a 500,000-event log. Once configured it works independently of the host, so access decisions, anti-passback, two-person control, tailgate control and occupancy limits continue while the network is down, and events upload when the link returns.

Cybersecurity

Communication to OnGuard uses TLS 1.2/1.3, links to LenelS2 Series 3 reader and I/O modules use AES-256 (AES-128 for Series 2), and data-at-rest encryption can be turned on. Firmware is stored in flash and can be updated with a background download.

Expansion Options

With OnGuard 7.6 and higher, the LNL-M2210 can run in an alternative configuration that drives up to eight RS-485 addressed devices, such as LNL-1300 and LNL-1320 reader interface modules, from reader port 1. A USB2-OTGE100 adapter adds a secondary network connection on a separate subnet.

Typical Applications

• Single office, classroom or suite doors
• IT closets, IDF rooms and server rooms
• Remote or detached doors with an existing network drop
• Retrofits where running new power to the door is costly
• Adding a door to an existing OnGuard system

Compatible Accessories

Compatible accessories for the Lenel LNL-M2210. Linked items are available at Affinitech Store; contact us for the others:

• Lenel LNL-1300-S3 Series 3 Single Reader Interface Module
• Lenel LNL-1320-S3 Series 3 Dual Reader Interface Module
• Lenel LNL-1100-S3 Series 3 Input Control Module
• Lenel LNL-1200-S3 Series 3 Output Control Module
• USB2-OTGE100 USB-to-Ethernet adapter (secondary NIC)
• LNL-1300-TAMPER tamper cable
• LNL-RPL-MTG-3G replacement mounting plate

Compare Lenel OnGuard Intelligent Controllers

Matching an existing X-Series system? See the Lenel LNL-X2210.

Explore More

• Network Door Controllers
• All LenelS2 Products
• Access Control Readers
• Network I/O and Relay Modules

Frequently Asked Questions

What does the Lenel LNL-M2210 control?

One door with one or two readers, for example an entry reader and an exit reader. It has two supervised inputs, a cabinet tamper input and two Form-C relays.

Can the LNL-M2210 run on PoE?

Yes. It accepts PoE (IEEE 802.3af, 12.95 W), PoE+ (IEEE 802.3at, 25 W) or 12 VDC ± 10% at 1.8 A maximum.

How much power does it provide to readers?

Reader port power is 12 VDC, 600 mA maximum. Total 12 VDC output is 625 mA on PoE and 1.25 A on PoE+ or local 12 VDC, including reader and auxiliary power.

How many cardholders and events does it store?

Up to 240,000 cardholders in 6 MB of on-board flash and 500,000 events in backed RAM.

Does it keep working if the network goes down?

Yes. Once configured, the LNL-M2210 makes access decisions independently of the OnGuard host and stores events until the connection returns.

Which readers are supported?

Wiegand, clock and data, RS-485 including OSDP, keypads, LCD and biometric readers. Reader port 1 supports TTL, F/2F or 2-wire RS-485; reader port 2 supports TTL or F/2F.

How is communication secured?

TLS 1.2/1.3 to OnGuard, AES-256 to LenelS2 Series 3 reader and I/O modules (AES-128 for Series 2), and an optional data-at-rest encryption setting.

Can I add more readers or modules?

With OnGuard 7.6 and higher, an alternative configuration supports up to eight RS-485 addressed devices, such as LNL-1300 and LNL-1320 reader interface modules.

Which OnGuard versions support M-Series controllers?

LenelS2 states that M-Series controllers are not supported on OnGuard 7.4 or lower, and OnGuard 8.3 adds native M-Series support. Contact us to confirm your version before ordering.

What approvals does the LNL-M2210 carry?

FCC Part 15, CE, RoHS and UL 294.
