AXIS M3057-PLVE Mk II 6MP 360° Outdoor Panoramic Camera, 02109-001

AXIS M3057-PLVE Mk II Panoramic Camera – 6MP 360° Outdoor Mini Dome with IR

The AXIS M3057-PLVE Mk II is a 6MP panoramic mini dome that gives a complete 360° or 180° overview from a single camera. It dewarps panorama, quad, corner and corridor views in the camera, uses Lightfinder, Forensic WDR and OptimizedIR for detail from bright daylight to total darkness, and is built into an IP66, NEMA 4X and IK10 casing for indoor or outdoor use. It covers parking lots, entrances and courtyards.

Key Specifications

Full specifications are listed in the Detailed Specifications tab.

Why Choose the AXIS M3057-PLVE Mk II?

• 6MP sensor with a full 360° or 180° overview
• Dewarped panorama, quad, corner and corridor views from the camera
• Lightfinder and Forensic WDR up to 120 dB
• OptimizedIR with 20 m (66 ft) or more of reach
• IP66, NEMA 4X and IK10 outdoor-ready casing
• Axis Edge Vault with secure element (CC EAL 6+) and secure boot
• Alarm input and output on a terminal block

Complete 360° Overview

A 1.56 mm fisheye lens covers 183° horizontally and vertically. The camera streams the 360° overview at up to 2016x2016 and can stream up to four dewarped view areas at the same time, with digital PTZ, presets and guard tours.

Day and Night Performance

Forensic WDR up to 120 dB handles scenes with strong backlight, color video reaches down to 0.16 lux, and OptimizedIR with 850 nm LEDs lights the scene to 20 m (66 ft) or more, down to 0 lux.

Analytics and Event Handling

AXIS Video Motion Detection, AXIS Motion Guard, AXIS Fence Guard, AXIS Loitering Guard and active tampering alarm are included, and AXIS People Counter, AXIS Occupancy Estimator and AXIS Queue Monitor are supported. The terminal block adds one alarm input and one output.

Cybersecurity and Rugged Installation

Axis Edge Vault, a secure element (CC EAL 6+), signed OS and secure boot protect the device. The aluminum casing with a hard-coated polycarbonate dome is rated IP66, NEMA 4X and IK10 and runs from -40 °C to 50 °C on PoE Class 3, with a mounting bracket included.

Typical Applications

• Parking lots and drop-off areas
• Building entrances and courtyards
• School playgrounds and campus open areas
• Warehouse floors and loading areas

Compatible Accessories

Compatible accessories for the AXIS M3057-PLVE Mk II, available at Affinitech Store:

• AXIS T94T02D Pendant Kit
• AXIS TM3808-E Skin Cover Black (4-pack)
• AXIS T94S02L Recessed Mount
• AXIS T6101 Audio and I/O Interface
• AXIS T6112 Audio and I/O Interface
• AXIS Surveillance Card 128 GB

Compare AXIS M30 Mini Domes

Explore More

• Browse the full Panoramic Cameras collection at Affinitech Store
• See more Outdoor Cameras at Affinitech Store
• Compare with the AXIS M4317-PLVE
• Compare with the AXIS M3077-PLVE

Frequently Asked Questions About AXIS M3057-PLVE Mk II

What resolution does the AXIS M3057-PLVE Mk II capture?

The 360° overview streams at up to 2016x2016, and dewarped views reach up to 2560x1920. AXIS describes the sensor as 6MP.

What area does it cover?

A full 360° or 180° overview, from a 1.56 mm lens with a 183° horizontal and vertical field of view.

Which dewarped views are available?

Panorama, double panorama, quad view, corner left/right, double corner, corridor and up to four view areas.

Does it have built-in IR?

Yes. OptimizedIR with 850 nm LEDs reaches 20 m (66 ft) or more depending on the scene.

Can it be installed outdoors?

Yes. The casing is rated IP66, NEMA 4X and IK10 and operates from -40 °C to 50 °C (-40 °F to 122 °F).

What is the minimum light sensitivity?

0.16 lux in color and 0.03 lux in black and white at 50 IRE, F2.0, and 0 lux with IR illumination on.

Which analytics are included?

AXIS Video Motion Detection, AXIS Motion Guard, AXIS Fence Guard, AXIS Loitering Guard and active tampering alarm.

How is it powered?

Power over Ethernet (IEEE 802.3af/802.3at Type 1 Class 3), typical 8.0 W and max 11.9 W.

What cybersecurity features does it have?

Axis Edge Vault with a secure element (CC EAL 6+), secure keystore, secure boot and signed OS, plus IEEE 802.1X and IEEE 802.1AE (MACsec).

Does it support local storage?

Yes, microSD/microSDHC/microSDXC with SD card encryption, plus recording to network-attached storage.

Has the AXIS M3057-PLVE Mk II been replaced?

Yes. AXIS has replaced it with the AXIS M4317-PLVE, which is available at Affinitech Store.
