Hanwha Vision LND-6012R 2MP Indoor IR Dome Camera

Brand: Hanwha Vision America
SKU:
LND-6012R
Condition:
New
(No reviews yet) Write a Review
Price: $147.55

Description

Newer model available: Hanwha Vision has discontinued the Hanwha Vision LND-6012R and has not named a direct replacement. Contact Affinitech Store for current availability and the closest current model.

Hanwha Vision LND-6012R – 2MP Indoor IR Dome

The Hanwha Vision LND-6012R is a 2MP indoor IR dome camera built for classrooms, retail and offices. It offers 1920x1080 (2MP) video at up to 30 fps, a 2.8mm lens with a 113.7° horizontal view and built-in IR reaching 20 m (66 ft).

Key Specifications

Max video resolution 1920x1080 (2MP)
Max frames per second 30 fps
Image sensor 2 MP 1/2.8" CMOS
Focal length / lens 2.8mm
Horizontal field of view 113.7°
Min illumination (color) 0.1 lux
Built-in IR 20 m (66 ft)
Power PoE 802.3af (15 W)
Operating temperature 14 to 131°F / -10 to 55°C

Full specifications are listed in the Detailed Specifications tab.

Why Choose the Hanwha Vision LND-6012R?

  • 1920x1080 (2MP) video at up to 30 fps
  • 2.8mm lens and a 113.7° horizontal view
  • Built-in IR: 20 m (66 ft)
  • Power: PoE 802.3af (15 W)

Clear Video Day and Night

The LND-6012R captures color video down to 0.1 lux; it has built-in IR that reaches 20 m (66 ft).

Coverage and Resolution

For the LND-6012R: a 2.8mm lens covers a 113.7° horizontal field of view; resolution is up to 1920x1080 (2MP) at 30 fps.

Analytics and Events

Onboard analytics and event features include Motion Detection (4 Rectangular Zones), Tampering.

Built-In Cybersecurity

Security features include Digest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering, User Access Log.

Installation and Integration

Key installation details: power input: PoE 802.3af (15 W); operating temperature: 14 to 131°F / -10 to 55°C; edge storage: Single Slot: microSD/microSDHC [32 GB Maximum]; compression: H.264, MJPEG; integration: ONVIF.

Typical Applications

  • Classrooms and school hallways
  • Retail floors and checkout areas
  • Offices and lobbies
  • Hallways and stairwells

Compare Hanwha Vision L Series Dome Cameras

ModelMax resolutionTypeBest for
Hanwha Vision LND-6012R (this camera) 2MP Indoor IR dome camera Classrooms, retail and offices
Hanwha Vision LND-6032R 2MP Indoor IR dome camera Classrooms, retail and offices
Hanwha Vision LND-6072R 2MP Indoor IR dome camera Classrooms, retail and offices
Hanwha Vision LNV-6012R 2MP Outdoor IR vandal dome camera Entrances, building perimeters and parking areas
Hanwha Vision LNV-6022R 2MP Outdoor IR vandal dome camera Entrances, building perimeters and parking areas
Hanwha Vision LNV-6032R 2MP Outdoor IR vandal dome camera Entrances, building perimeters and parking areas
Hanwha Vision LNV-6072R 2MP Outdoor IR vandal dome camera Entrances, building perimeters and parking areas

Explore More

Frequently Asked Questions About Hanwha Vision LND-6012R

What resolution does the Hanwha Vision LND-6012R capture?

Up to 1920x1080 (2MP) at 30 fps.

What lens does it use?

2.8mm; horizontal field of view 113.7°.

Does it see in the dark?

Yes. Built-in IR reaches 20 m (66 ft).

What is the operating temperature range?

14 to 131°F / -10 to 55°C.

How is it powered?

PoE 802.3af (15 W).

What video compression does it support?

H.264, MJPEG.

Does it support onboard storage?

Yes: Single Slot: microSD/microSDHC [32 GB Maximum].

What cybersecurity features are built in?

Digest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering, User Access Log.

Is it ONVIF compliant?

Yes, ONVIF is supported.

What analytics are supported?

Motion Detection (4 Rectangular Zones), Tampering.

What are the dimensions and weight of the Hanwha Vision LND-6012R?

Dimensions: ø110x86 mm (ø4.33x3.39 in). Weight: 0.6 lb.

View AllClose

Detailed Specifications

Hanwha Vision LND-6012R Specifications

SpecificationDetails
Specifications
Sensor2 MP 1/2.8" CMOS
Focal Length2.8mm
Maximum Aperturef/2
Lens Field of ViewHorizontal: 113.7°; Vertical: 61.5°; Diagonal: 134.4°
IR Cut FilterMechanical
Day/NightYes
Minimum IlluminationColor: 0.1 Lux; B&W: 0 Lux
Camera Angle AdjustmentHorizontal: 0 to 350°; Vertical: 0 to 67°
Streaming Resolution1920 x 1080 at 30 fps (H.264)
Supported Video CompressionH.264, MJPEG
Multi-View StreamingYes, 3 Streams
Built-In MicNo
SecurityDigest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering, User Access Log
Supported ProtocolsARP, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, ICMP, IGMP, IPv4/v6, LLDP, NTP, QoS Layer 3 DiffServ, RTCP, RTP, RTSP, SMTP, SNMP v1/v2c/v3 (MIB-II), SSL/TLS, TCP, UDP, UPnP
Application Programming Interface (API)ONVIF Profiles G, S & T, SUNAPI (HTTP API)
AnalyticsMotion Detection (4 Rectangular Zones), Tampering
Event TriggerYes
Event ActionRecording, Notification, Alarm
Data StreamingYes
Windows OS SupportWindows 7, 8.1, 10
Mac OS SupportmacOS 10.14, macOS 10.13, macOS 10.12
Operating Temperature14 to 131°F / -10 to 55°C
Storage Temperature-22 to 131°F / -30 to 55°C
Operating Humidity0 to 90%
Memory512 MB RAM / 256 MB Flash
Media/Memory Card SlotSingle Slot: microSD/microSDHC [32 GB Maximum]
Pan/TiltNone
I/O Connections1 x RJ45
IR Range65.62' / 20 m
Internal StorageNone
Power SourcePoE 802.3af (15 W)
Power Consumption5 W
Material of ConstructionPlastic
Package Weight0.93 lb
Box Dimensions (LxWxH)5.6 x 5.6 x 4.6"
Mechanical
Product Dimensionsø110x86 mm (ø4.33x3.39 in)
Product Weight0.6 lb
