2N IP Force 2.0 1-Button Audio-Only Intercom, 03359-001

2N IP Force 2.0 1-button audio-only Intercom – IP69, IK10, 10 W Audio

The 2N IP Force 2.0 1-button audio-only is a second-generation, vandal-resistant IP audio intercom with one call button and no camera. It leaves out the camera for entrances where a voice call is all that is needed, and still gives you a 10 W speaker, two microphones, noise suppression and an aluminium body rated IP69 and IK10. It runs on PoE+ or 12 V DC and is aimed at gates, loading docks and utility entrances.

This is the 2N IP Force 2.0 generation (order number 03359-001). It is not interchangeable with the first-generation 2N IP Force; accessories and modules below are the ones 2N lists for IP Force 2.0.

Key Specifications

Full specifications are listed in the Detailed Specifications tab.

Why Choose the 2N IP Force 2.0 One-button audio-only Model?

• No camera, which suits privacy-sensitive entrances and keeps the unit simpler
• Same IP69 aluminium body as the video versions, in an audio-only configuration
• Two microphones with noise cancellation and adaptive speaker volume for intelligible calls outdoors
• IP69 and IK10 body for rain, dust, wash-down and impact
• Gigabit PoE+ or 12 V DC power, with a tamper-aware security relay available for lock circuits
• SIP 2.0 with SIPS and SRTP, plus ONVIF, SNMP and 802.1x for network integration
• Secure boot, signed firmware and a secure key store
• 5-year warranty stated by 2N

Built for the Weather and for Abuse

The housing is ADC12 aluminium with chromate treatment and a powder-coated finish. 2N specifies an IP69 cover rating, IK10 for the body and IK08 for the front panel, and an operating range of -30 °C to +55 °C at 10% to 95% non-condensing humidity. It can be mounted on the surface, flush in brick or plasterboard with the matching boxes, or on a stand.

Clear Audio at a Noisy Door

Two integrated microphones, acoustic echo cancellation and a 10 W / 4 Ω amplifier and speaker deliver up to 94 dB at 1 m. 2N quotes a Speech Transmission Index of 0.89, adaptive volume that follows ambient noise, and automatic audio-loop tests. Codecs include G.711, G.729, G.722 and L16/16 kHz over SIP (UDP, TCP or TLS) with RTP or SRTP.

Audio-Only, Ready to Grow

With no camera in this version, the unit relies on audio and the door-control I/O for visitor handling. You can still add a keypad or RFID capability where the variant allows it, connect an external IP camera input (up to 1280 x 720 at 30 fps in H.264) and integrate it with existing VMS or CCTV through ONVIF.

Door Control, Connectivity and Management

A solid-state relay (30 V, 1 A AC/DC), a 12 V / 0.6 A active switch output and three configurable inputs handle locks and sensors, and a VBus connector accepts Verso 2.0 modules. Settings can be made through the web interface, the My2N Management Platform or 2N Access Commander.

Typical Applications

• Gates, loading docks and utility entrances
• Industrial and logistics sites
• Schools, campuses and public buildings
• Parking facilities and perimeter gates
• Residential and mixed-use complexes

Compatible Accessories

Compatible accessories for the 2N IP Force 2.0. Linked items are available at Affinitech Store; contact us for the others:

• 2N IP Force Brick Flush Mounting Box (01348-001)
• 2N IP Force Plasterboard Flush Mounting Box (01349-001)
• 2N IP Force Security Screws (01345-001)
• 2N Gooseneck Stand (01351-001)
• 2N Double Gooseneck Stand (01550-001)
• 2N Installation Adapter for IP Force and IP Safety (01352-001)
• 2N Additional Switch and Tamper (01350-001)
• 2N Security Relay (01386-001)
• 2N External IP Relay, 1 Output, 1 Input (01397-001)
• 2N External IP Relay, 4 Outputs (01398-001)
• 2N PoE+ Injector (02445-001)
• 2N 12 V Power Supply, US Adapter (02520-001)

Compare 2N IP Force 2.0 Intercoms

Looking for the first generation? The older 2N IP Force 1-button video intercom (01337-001) is a different model and not interchangeable with IP Force 2.0 parts.

Explore More

• Browse all Network Door Stations and Intercoms at Affinitech Store
• See the full Access Control collection
• See Readers for credential options

Frequently Asked Questions About the 2N IP Force 2.0 One-button audio-only Model

What is the 2N IP Force 2.0 1-button audio-only?

It is the one-button audio-only version of the second-generation 2N IP Force intercom, order number 03359-001, with one call button and no camera.

Does it have a camera?

No. This is the audio-only version; 2N also makes video versions of IP Force 2.0 with a 5MPx camera.

How tough is it?

The body is rated IP69 and IK10, with IK08 for the front panel, and it operates from -30 °C to +55 °C.

How is it powered?

By PoE+ (IEEE 802.3at) over Gigabit Ethernet or by a 12 V / 4 A DC supply.

How loud is the speaker?

The 10 W / 4 Ω speaker reaches a maximum of 94 dB at 1 kHz and 1 m, with adaptive volume control.

Which protocols does it support?

SIP 2.0 with SIPS and SRTP, ONVIF, RTSP, RTP, HTTP and HTTPS, SNMP, TR069, 802.1x, SMTP, DHCP option 66, TFTP and Syslog.

How does it control a door?

Through a solid-state relay rated 30 V / 1 A AC/DC, a 12 V / 0.6 A active output and three inputs. A separate 2N Security Relay can be added for lock circuits.

Can I add a card reader?

This variant is not the card-reader-ready version. If you need RFID, look at the card-reader-ready versions in the compare table above.

Is it the same as the first-generation 2N IP Force?

No. IP Force 2.0 is a separate generation with its own order numbers and modules, so first-generation accessories should not be assumed to fit.

What warranty applies?

2N states a 5-year warranty for the IP Force 2.0 family.
