Hanwha Vision SLA-F2480DSA 5MP, Door Jamb with 2.45mm Lens (silver)

Brand: Hanwha Vision America
SKU:
SLA-F2480DSA
Condition:
New
(No reviews yet) Write a Review
MSRP: $335.00
Price: $217.75
— You save $117.25

Description

Hanwha Vision SLA-F2480DSA – 5MP, Door Jamb with 2.45mm Lens (silver)

The Hanwha Vision SLA-F2480DSA is a 5MP, Door Jamb with 2.45mm Lens (silver). Highlights are listed below, and the full specifications are in the Detailed Specifications tab.

Key Specifications

Storage Condition - Temperature -50°C~+60°C(-58°F~+140°F)
Supported Products PNM-C20000QB
Product Dimensions 48.29(W)x37.0(H)x174.01(D)mm(1.9x1.46x6.85"), Cable: 8m(26.2ft)
Product Weight 124.5g(0.27lb), Cable: 350g(0.77lb)

Full specifications are listed in the Detailed Specifications tab.

Highlights

  • 5MP
  • Door Jamb Head with 2.45mm lens module
  • FoV (H:123°, V:91°)
  • Compatible with PNM-C20000QB
  • 8m (26ft) cable included
  • Silver color
  • Indoor

Note: Compatible with PNM-C20000QB

Explore More

Frequently Asked Questions About Hanwha Vision SLA-F2480DSA

What is the Hanwha Vision SLA-F2480DSA?

5MP, Door Jamb with 2.45mm Lens (silver). 5MP, Door Jamb Head with 2.45mm lens module, FoV (H:123°, V:91°), Compatible with PNM-C20000QB, 8m (26ft) cable included, Silver color, Indoor

Where can I find the full specifications?

The full manufacturer specifications are listed in the Detailed Specifications tab.

View AllClose

Detailed Specifications

Hanwha Vision SLA-F2480DSA Specifications

SpecificationDetails
Video
Imaging Device - Size1/2.8"
Imaging Device - TypeCMOS
Min. Illumination (Lux) - Color(1/30sec, 30IRE)0.08
Min. Illumination (Lux) - BW(1/30sec, 30IRE)0.08
Lens
Focal Length (mm)2.45
Max. Aperture Ratio (F number) - Wide2.0
Max. Aperture Ratio (F number) - Tele2.0
Angular Field of View - Horizontal123°
Angular Field of View - Vertical91°
Angular Field of View - Diagonal159°
Mount TypeRJ12 connected with main unit
Focus ControlFixed
Pan / Tilt / Rotate
Pan / Tilt / Rotate Range - PanFlexible panning ±30°
Environmental & Electrical
Operating Condition - Temperature-10°C ~ +55°C (+14°F ~ +131°F)
Operating Condition - Humidity0~95% RH
Storage Condition - Temperature-50°C~+60°C(-58°F~+140°F)
Storage Condition - HumidityLess than 90% RH
Mechanical
ColorSilver
MaterialPlastic
Product Dimensions48.29(W)x37.0(H)x174.01(D)mm(1.9x1.46x6.85"), Cable: 8m(26.2ft)
Product Weight124.5g(0.27lb), Cable: 350g(0.77lb)
Supported ProductsPNM-C20000QB
Certification & Standards
EMCFCC 47 CFR 15 Subpart B Class A, ICES-3(A)/NMB-3(A), CE/UKCA EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3, VCCI CISPR 32 Class A, RCM AS/NZS CISPR 32 Class A, KS C 9832 Class A, KS C 9835
SafetyUL 62368-1, CAN/CSA C22.2 NO. 62368-1
EnvironmentIEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78
