AXIS Q6325-LE 2MP 31x Outdoor AI IR PTZ Camera, 03313-001
Description
AXIS Q6325-LE PTZ Camera – 2 MP AI-Powered Outdoor PTZ with 31x Zoom and OptimizedIR
The AXIS Q6325-LE is a 2 MP (1080p) outdoor PTZ camera with a light-sensitive 1/2″ sensor, 31x optical zoom and OptimizedIR, built on ARTPEC-9 with a deep learning processing unit. AXIS Object Analytics detects and classifies humans, vehicles and vehicle types on the camera, Axis Zipstream with AV1, H.264 and H.265 keeps bandwidth and storage down, and Axis Edge Vault protects the device. The IP66-, IK10-, NEMA 4X- and NEMA TS 2-rated casing suits campuses, parking lots and large open areas. The midspan is not included: it runs on a 60 W or 30 W midspan, with full pan/tilt speed and 250 m IR range on 60 W.
Key Specifications
| Max video resolution | 1920x1080 (2 MP) |
| Max frames per second | Up to 50/60 fps in all resolutions |
| Lens | Varifocal 6.91–214.64 mm, F1.36–F4.6 |
| Horizontal field of view | 60.6°–2.0° |
| Optical zoom | 31x optical, 12x digital (372x total) |
| Pan/tilt range and speed | 360° endless, 0.05°–500°/s with 60 W midspan; tilt +20 to -90° |
| Presets/guard tours | 300 preset positions, up to 100 guard tours, tour recording |
| Autotracking | Autotracking 2 |
| Wide dynamic range | Forensic WDR, up to 120 dB |
| Min illumination (color) | 0.09 lux at 30 IRE, F1.36 |
| Built-in IR | OptimizedIR, 250 m (820 ft) with 60 W midspan |
| Power / IP / IK | PoE IEEE 802.3bt Class 6 (60 W midspan) or 802.3at Class 4 (30 W midspan); IP66, IK10 |
Full specifications are listed in the Detailed Specifications tab.
Why Choose the AXIS Q6325-LE?
- 2 MP (1080p) video (1920x1080) at up to 50/60 fps
- 1/2″ sensor with 31x optical zoom
- OptimizedIR with long-life 850 nm LEDs, 250 m (820 ft) or more with a 60 W midspan (190 m (623 ft) with a 30 W midspan)
- ARTPEC-9 with a deep learning processing unit running AXIS Object Analytics and AXIS Image Health Analytics
- Autotracking 2, advanced gatekeeper and Orientation Aid PTZ
- Axis Zipstream with AV1, H.264 and H.265
- Axis Edge Vault with a FIPS 140-3 Level 3 secure element, signed video and secure boot
- IP66, IK10, NEMA 4X and NEMA TS 2 (74 °C) rated; Arctic Temperature Control start-up at -40 °C
Extreme Low-Light Performance
The 1/2″ progressive scan sensor, Lightfinder 2.0 and Forensic WDR (up to 120 dB depending on scene) hold color and detail in difficult light, with color video down to 0.09 lux at 30 IRE, F1.36. Removable IR-cut and IR-pass filters and OptimizedIR with power-efficient 850 nm LEDs reach 250 m (820 ft) or more with a 60 W midspan (190 m (623 ft) with a 30 W midspan), and defogging and electronic image stabilization help on hazy or windy days.
Long-Range Zoom and Fast PTZ
The 6.91–214.64 mm lens gives a 60.6°–2.0° horizontal field of view with 31x optical zoom (372x total). Continuous 360° pan at up to 500°/s and +20 to -90° tilt at up to 450°/s on a 60 W midspan (150°/s on a 30 W midspan), 300 preset positions, guard tours, tour recording, nadir flip and a control queue make it easy to follow fast-moving objects across a large site.
AI-Powered Analytics on the Edge
The ARTPEC-9 deep learning processing unit runs AXIS Object Analytics to detect, classify and count humans and vehicles (cars, buses, trucks, bikes), with line crossing, object in area, time in area, crossline counting and tailgating detection scenarios. AXIS Image Health Analytics warns if the image is blocked, redirected, blurred or underexposed, autotracking 2 follows objects with click-and-track, and AXIS Scene Metadata, AXIS Live Privacy Shield and AXIS Video Motion Detection are included. AXIS License Plate Verifier is supported.
Built-In Cybersecurity
Axis Edge Vault provides a secure element (CC EAL6+, FIPS 140-3 Level 3), system-on-chip security (TEE), Axis device ID, signed video, secure boot and an encrypted filesystem. IEEE 802.1X, IEEE 802.1AE (MACsec), HTTPS/HSTS, TLS v1.2/v1.3 and a host-based firewall protect the network connection.
Rugged Outdoor Installation
The IP66-, NEMA 4X- and IK10-rated aluminum casing is NEMA TS 2 rated up to 74 °C (165 °F), runs from -50 °C to 55 °C at full power with a 60 W midspan and starts up as low as -40 °C. The repaintable casing comes with a repaint template and paint paper, and an IP66-rated push-pull network connector keeps the cable entry sealed. The midspan is not included; choose a 60 W midspan for full performance.
Typical Applications
- School, hospital and corporate campuses
- Parking lots and parking structures
- City surveillance, intersections and roadways (NEMA TS 2 rated)
- Building perimeters and fence lines
- Ports, rail yards and logistics sites
- Stadiums, plazas and other large open areas
Compatible Accessories
Compatible accessories for the AXIS Q6325-LE. Linked items are available at Affinitech Store; contact us for the others:
- AXIS TU8003 90 W Connectivity Midspan
- AXIS TQ6808-E Hard-Coated Clear Dome
- AXIS TQ6815-E Hard-Coated Smoked Dome
- AXIS Surveillance Card 256 GB
- AXIS Surveillance Card 512 GB
- AXIS T91/T94 mounting accessories (no mounting bracket is included; contact us for the right wall, pole or corner mount)
Compare AXIS Q63 PTZ Cameras
| Model | Max resolution | Type | Best for |
|---|---|---|---|
| AXIS Q6325-LE (this camera) | 1920x1080 (2 MP) | Outdoor AI PTZ, 31x zoom, IR, midspan not included | Long-range PTZ coverage at a lower cost |
| AXIS Q6355-LE | 1920x1080 (2 MP) | Outdoor AI PTZ, 31x zoom, laser focus, IR 300 m, 90 W midspan included | Extreme low light, campuses and large lots |
| AXIS Q6355-LE No Midspan | 1920x1080 (2 MP) | Same camera as the Q6355-LE, midspan not included | Sites with an existing High PoE source |
| AXIS Q6358-LE | 3840x2160 (4K UHD) | Outdoor 4K AI PTZ, 31x zoom, laser focus, IR 300 m, 90 W midspan included | Wide areas that need 4K detail |
| AXIS Q6358-LE No Midspan | 3840x2160 (4K UHD) | Same camera as the Q6358-LE, midspan not included | 4K PTZ on an existing High PoE source |
Explore More
- Browse the full PTZ Cameras collection at Affinitech Store
- Shop PTZ Dome Cameras at Affinitech Store
- Shop Outdoor Cameras at Affinitech Store
- Shop IR Cameras at Affinitech Store
- See more AI-Powered Cameras at Affinitech Store
Frequently Asked Questions About AXIS Q6325-LE
What resolution does the AXIS Q6325-LE record?
1920x1080 (2 MP (1080p)) at up to 50/60 fps in all resolutions.
How much zoom does it have?
31x optical zoom and 12x digital zoom, for 372x total zoom, with a 6.91–214.64 mm, F1.36–F4.6 lens.
What are the pan and tilt ranges?
360° endless pan at 0.05°–500°/s and +20 to -90° tilt at 0.05°–450°/s with a 60 W midspan; with a 30 W midspan both run at up to 150°/s.
How far does the built-in IR reach?
OptimizedIR with 850 nm LEDs reaches 250 m (820 ft) or more with a 60 W midspan (190 m (623 ft) with a 30 W midspan).
Which analytics are included?
AXIS Object Analytics, AXIS Image Health Analytics, AXIS Live Privacy Shield, AXIS Scene Metadata, AXIS Video Motion Detection, AXIS OSDI Zone, Orientation Aid PTZ, advanced gatekeeper and autotracking 2. AXIS License Plate Verifier is supported.
Which video formats does it support?
AV1, H.264, H.265 and Motion JPEG, with Axis Zipstream in AV1, H.264 and H.265.
Is a midspan included?
No. The AXIS Q6325-LE ships without a midspan. With a 60 W midspan (IEEE 802.3bt Class 6) it reaches full pan/tilt speed and 250 m IR range; with a 30 W midspan (IEEE 802.3at Class 4) pan/tilt runs at up to 150°/s and IR reaches 190 m.
How is it powered?
PoE IEEE 802.3bt Class 6 with a 60 W midspan (typical 13 W without IR, max 51 W) or IEEE 802.3at Class 4 with a 30 W midspan (max 25 W).
Can it be installed outdoors?
Yes. It is IP66-, NEMA 4X- and IK10-rated, NEMA TS 2 rated up to 74 °C (165 °F) and runs from -50 °C to 55 °C at full power with a 60 W midspan.
Does it support audio?
Yes. Audio input and output run through portcast technology.
Does it have local storage?
Yes. It supports SD/SDHC/SDXC cards with AES-XTS-Plain64 256-bit encryption, plus recording to network-attached storage (NAS).
What warranty does it have?
A 5-year AXIS warranty.
Detailed Specifications
AXIS Q6325-LE Specifications
| Specification | Details |
|---|---|
| Camera | |
| Variants | AXIS Q6325-LE (midspan not included) |
| Image sensor | 1/2″ progressive scan CMOS |
| Optical zoom | 31x |
| Lens | Varifocal 6.91–214.64 mm, F1.36–F4.6 |
| Horizontal field of view | 60.6°–2.0° |
| Vertical field of view | 36.5°–1.1° |
| Focus and iris | Autofocus, P-iris |
| Day and night | Automatically removable infrared-cut filter; removable infrared-pass filter |
| Minimum illumination | Color: 0.09 lux at 30 IRE, F1.36; B/W: 0.002 lux at 30 IRE, F1.36; color: 0.4 lux at 50 IRE, F1.36; B/W: 0.008 lux at 50 IRE, F1.36; 0 lux with IR illumination on |
| Shutter speed | 1/111000 s to 1/2 s |
| Pan | With 60 W midspan: 360° endless, 0.05°–500°/s; with 30 W midspan: 0.05°–150°/s |
| Tilt | With 60 W midspan: +20 to -90°, 0.05°–450°/s; with 30 W midspan: 0.05°–150°/s |
| Zoom | 31x optical, 12x digital, total 372x zoom |
| PTZ functions | Nadir flip, 300 preset positions, tour recording (max 10, max duration 16 minutes each), guard tour (max 100), control queue, on-screen directional indicator, set new pan 0°, adjustable zoom speed, speed dry |
| System on Chip | |
| Model | ARTPEC-9 |
| Memory | 4 GB RAM, 8 GB Flash |
| Compute capabilities | Deep learning processing unit (DLPU) |
| Video | |
| Video compression | AV1; H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles; H.265 (MPEG-H Part 2/HEVC) Main Profile; Motion JPEG |
| Resolution | 1920x1080 (HDTV 1080p) to 320x180 |
| Frame rate | Up to 50/60 fps (50/60 Hz) in all resolutions |
| Video streaming | Multiple, individually configurable streams in AV1, H.264, H.265 and Motion JPEG; Axis Zipstream technology in AV1, H.264 and H.265; controllable frame rate and bandwidth; VBR/ABR/MBR AV1/H.264/H.265; low latency mode; video streaming indicator |
| Signal-to-noise ratio | >55 dB |
| Image settings | Compression, color, brightness, sharpness, white balance, exposure control, exposure zones, image freeze on PTZ, scene profiles, rotation, electronic image stabilization (EIS), defogging, contrast, local contrast, autofocus |
| Wide dynamic range | Forensic WDR: up to 120 dB depending on scene |
| Privacy masks | 100 individual polygon privacy masks including mosaic and chameleon privacy masks |
| Audio | |
| Audio input | Input through portcast technology |
| Audio output | Output through portcast technology |
| Network | |
| Security | Multi-level user, IP address filtering, HTTPS encryption, IEEE 802.1x (EAP-TLS), network access control, user access log, centralized certificate management, secure keystore (CC EAL4 certified), TPM-equivalent secure element (CC EAL 6+, FIPS 140-3 Level 3) |
| Network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, HTTP/2, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTCP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, ARP, SSH, NTCIP, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| System Integration | |
| Application Programming Interface | Open API for software integration, including VAPIX® and AXIS Camera Application Platform specifications; One-Click Cloud Connection; ONVIF® Profile G, ONVIF® Profile M, ONVIF® Profile S and ONVIF® Profile T |
| Onscreen controls | IR illumination, speed dry |
| Event conditions | Device status: above operating temperature, above or below operating temperature, below operating temperature, fan failure, IP address removed, IP address blocked, live stream active, network lost, new IP address, PTZ power failure, system ready, within operating temperature; Edge storage: recording ongoing, storage disruption, storage health issues detected; I/O: manual trigger, virtual input (only available with midspan); MQTT: MQTT client connected; PTZ: PTZ malfunctioning, PTZ movement, PTZ preset position reached, PTZ ready; Scheduled and recurring: schedule; Video: average bitrate degradation, day-night mode |
| Event actions | Day-night mode; defog mode; illumination (use lights); images: FTP, SFTP, HTTP, HTTPS, network share and email; MQTT publish; notification: email, HTTP, HTTPS, TCP; overlay text; recordings: record video; security: erase configuration; SNMP trap messages; video clips: FTP, HTTP, HTTPS, SFTP, email, network share |
| Analytics | |
| Included applications | AXIS Object Analytics, AXIS Scene Metadata, AXIS Video Motion Detection, AXIS OSDI Zone, Orientation Aid PTZ, Advanced Gatekeeper, Autotracking 2, AXIS Live Privacy Shield, AXIS Image Health Analytics |
| Supported applications | AXIS License Plate Verifier; support for AXIS Camera Application Platform (ACAP) third-party applications |
| AXIS Object Analytics | Object classes: humans, vehicles (types: cars, buses, trucks, bikes, other). Scenarios: line crossing, object in area, time in area, crossline counting, tailgating detection, PPE monitoring (beta), motion in area, motion line crossing. Up to 10 scenarios; trajectories, color-coded bounding boxes and tables; polygon include/exclude areas; perspective configuration; ONVIF Motion Alarm event |
| AXIS Image Health Analytics | Tampering: blocked image, redirected image; image degradation: blurred image, underexposed image; sensitivity and validation period settings |
| AXIS Scene Metadata | Object classes: humans, faces, vehicles (types: cars, buses, trucks, bikes), license plates. Object attributes: vehicle color, upper/lower clothing color, confidence, position |
| Approvals | |
| EMC | EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, CISPR 35, EAC, EN 50121-4; Australia/New Zealand: RCM AS/NZS CISPR 32 Class A; Canada: ICES-3(A)/NMB-3(A); Japan: VCCI Class A; Korea: KS C 9835, KS C 9832 Class A; USA: FCC Part 15 Subpart B Class A; Railway: IEC 62236-4 |
| Safety | IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, IEC/EN 62471 risk group 2, IEC 60825-1 Class 1 |
| Environment | IEC/EN 62262 IK10, IEC/EN 60529 IP66, NEMA 250 Type 4X, NEMA TS 2 (2.2.7–2.2.9), IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, ISO 21207 (Method B), ISO 12944-6 C5, ICC-ES AC156, IEC 60068-2-57 |
| Network | IPv6 USGv6, NIST SP500-267 |
| Cybersecurity | ETSI EN 303 645, BSI IT Security Label, FIPS 140 |
| Cybersecurity | |
| Edge security (software) | Signed OS, brute force delay protection, digest authentication and OAuth 2.0 RFC6749 OpenID Authorization Code Flow for centralized ADFS account management, password protection, AES-XTS-Plain64 256bit SD card encryption |
| Edge security (hardware) | Axis Edge Vault cybersecurity platform; secure keystore: secure element (CC EAL6+, FIPS 140-3 Level 3), system-on-chip security (TEE); Axis device ID, signed video, secure boot, encrypted filesystem (AES-XTS-Plain64 256bit) |
| Network security | IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2), IEEE 802.1AE (MACsec PSK/EAP-TLS), HTTPS/HSTS, TLS v1.2/v1.3, Network Time Security (NTS), X.509 Certificate PKI, host-based firewall |
| Documentation | AXIS OS Hardening Guide, Axis Vulnerability Management Policy, Axis Security Development Model, AXIS OS Software Bill of Material (SBOM) |
| General | |
| Casing | IP66-, NEMA 4X- and IK10-rated; color: white NCS S 1002-B; repaintable metal casing (aluminum); hard-coated polycarbonate (PC) clear dome with Sharpdome technology |
| Power | PoE, IEEE 802.3bt Class 6 (60 W midspan): typical 13 W (no IR), max 51 W; PoE, IEEE 802.3at Class 4 (30 W midspan): full power profile typical 13 W (no IR), max 25 W; power profiles, power meter. Midspan not included |
| Power-optimized performance | Low power profile: IEEE 802.3bt Class 6 typical 13 W (no IR), max 29 W (with IR: 39 W); IEEE 802.3at Class 4 typical 13 W (no IR), max 20 W (with IR: 23 W); operating -10 °C to 55 °C (14 °F to 131 °F) with 60 W or 30 W midspan |
| Connectors | RJ45 10BASE-T/100BASE-TX/1000BASE-T; RJ45 push-pull connector (IP66) |
| IR illumination | OptimizedIR with power-efficient, long-life 850 nm IR LEDs; range of reach 250 m (820 ft) or more with 60 W midspan, 190 m (623 ft) or more with 30 W midspan, depending on the scene |
| Storage | Support for SD/SDHC/SDXC card; SD card encryption (AES-XTS-Plain64 256bit); recording to network-attached storage (NAS) |
| Operating conditions | Full power with 60 W midspan: -50 °C to 55 °C (-58 °F to 131 °F); full power profile with 30 W midspan: -30 °C to 55 °C (-22 °F to 131 °F); maximum temperature according to NEMA TS 2 (2.2.7): 74 °C (165 °F); Arctic Temperature Control: start-up as low as -40 °C (-40 °F); humidity 10–100% RH (condensing) |
| Storage conditions | -40 °C to 65 °C (-40 °F to 149 °F); humidity 5–95% RH (non-condensing) |
| Dimensions | Height: 261 mm (10.3 in); with weather shield: ø 239 mm (9.4 in); without weather shield: ø 192 mm (7.6 in) |
| Weight | 4332 g (9.55 lb) |
| Included accessories | Installation guide, Windows® decoder 1-user license, IP66-rated network connector, repaint template, paint paper (midspan not included) |
| Optional accessories | AXIS TQ6808-E Hard-Coated Clear Dome, AXIS TQ6815-E Hard-Coated Smoked Dome, AXIS TU8003 90 W Connectivity Midspan, AXIS T91/T94 Mounting Accessories, AXIS Surveillance Cards |
| Video management software | AXIS Companion, AXIS Camera Station and video management software from Axis Application Development Partners |
| Languages | English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Polish, Traditional Chinese, Dutch, Czech, Swedish, Finnish, Turkish, Thai, Vietnamese |
| Warranty | 5-year warranty |
| Sustainability | PVC free; RoHS (EU RoHS Directive 2011/65/EU and 2015/863, EN IEC 63000:2018); REACH ((EC) No 1907/2006); renewable carbon-based plastic content 23% (recycled 18%, bio-based 5%); screened for conflict minerals in accordance with OECD guidelines |
| Detect, Observe, Recognize, Identify (DORI) | |
| DORI (wide / tele) | Detect (25 px/m): 65.8 m (216 ft) / 1749.3 m (5737.7 ft); Observe (63 px/m): 26.1 m (85.6 ft) / 693.7 m (2275 ft); Recognize (125 px/m): 13.2 m (43.3 ft) / 349.2 m (1145 ft); Identify (250 px/m): 6.6 m (21.6 ft) / 174.2 m (571.4 ft) |
