AXIS Communications M4337-PLVE Panoramic Network Camera, 03130-001

AXIS M4337-PLVE 6MP Panoramic IP Camera

The AXIS M4337-PLVE (Part #03130-001) is a professional 6 MP panoramic network camera designed to provide comprehensive 180° or 360° surveillance coverage with excellent image detail and minimal blind spots. Featuring a 1/1.6" CMOS sensor, up to 2464 x 2464 resolution, and an ultra-wide 185° horizontal and vertical field of view, the M4337-PLVE provides wide-area coverage from a single compact camera.

Designed for demanding indoor and outdoor security applications, the AXIS M4337-PLVE combines Lightfinder, Forensic WDR, OptimizedIR, Sharpdome 360 technology, and AI-powered analytics to deliver clear, reliable surveillance around the clock. Built-in infrared illumination provides reflection-free video in low-light conditions and complete darkness.

6MP 360° Panoramic Coverage

The AXIS M4337-PLVE uses a 1.7 mm stereographic lens and Sharpdome 360 technology to provide excellent image sharpness across the panoramic image, including the edges and corners. The camera delivers complete 180° or 360° coverage without blind spots, making it an efficient solution for monitoring large areas with a single camera.

The M4337-PLVE supports multiple viewing options, including panoramic, quad, corner, and corridor dewarped views. Camera-side dewarping provides clear, natural-looking images while improving usability and coverage. Up to four digital PTZ views can also be used to monitor specific areas of interest.

Advanced AI Video Analytics

Built-in AI-powered analytics provide intelligent surveillance capabilities directly on the camera. The M4337-PLVE includes AXIS Object Analytics, which can help detect, classify, track, and count people and vehicles.

Additional analytics include AXIS Image Health Analytics, AXIS Scene Metadata, and AXIS Video Motion Detection, providing valuable information for security monitoring and system automation.

Excellent Low-Light Image Quality

The AXIS M4337-PLVE is designed to deliver high-quality video in challenging lighting conditions. Axis Lightfinder provides excellent low-light performance, while Forensic WDR helps preserve important details in scenes containing both bright and dark areas.

Built-in OptimizedIR illumination with individual IR LEDs enables discreet, reflection-free surveillance in complete darkness. The camera can achieve 0 lux black-and-white illumination when IR is active.

Efficient Video Streaming and Storage

Axis Zipstream technology helps reduce bandwidth and storage requirements while preserving important image details. The camera supports AV1, H.264, and H.265 video compression, providing flexible options for modern video surveillance systems.

The M4337-PLVE supports multiple configurable video streams and includes a microSD card slot for local recording and storage.

Outdoor-Ready and Vandal Resistant

Designed for demanding environments, the AXIS M4337-PLVE features IP66-rated protection against dust and water and IK10-rated impact protection against vandalism and physical damage.

The camera operates in temperatures from -40°F to 122°F (-40°C to 50°C), making it suitable for year-round indoor and outdoor surveillance applications.

Built-In Cybersecurity

The M4337-PLVE includes Axis Edge Vault and hardware-based cybersecurity features designed to help protect the camera and sensitive information. Secure boot and a signed operating system help prevent unauthorized software or firmware from being installed on the device.

Key Features

• AXIS M4337-PLVE
• Part Number: 03130-001
• 6 MP panoramic network camera
• Maximum resolution: 2464 x 2464
• Up to 60 fps
• 180° or 360° panoramic coverage
• 185° horizontal and vertical field of view
• 1/1.6" progressive scan CMOS sensor
• 1.7 mm stereographic lens
• Sharpdome 360 technology
• Lightfinder
• Forensic WDR up to 120 dB
• Built-in OptimizedIR
• Individual IR LEDs
• Day/night functionality
• Camera-side dewarped views
• Panoramic, quad, corner, and corridor views
• Up to four digital PTZ views
• AXIS Object Analytics
• AXIS Image Health Analytics
• AXIS Scene Metadata
• AXIS Video Motion Detection
• Axis Zipstream
• AV1, H.264 and H.265 support
• Local microSD card storage
• IP66-rated
• IK10-rated
• Outdoor-ready design
• Operating temperature: -40°F to 122°F
• Axis Edge Vault cybersecurity
• 5-year Axis warranty

Ideal Applications

The AXIS M4337-PLVE is an excellent choice for wide-area video surveillance where comprehensive coverage from a single camera is desired, including:

• Retail stores and shopping centers
• Office buildings
• Commercial properties
• Schools and educational facilities
• Warehouses and distribution centers
• Parking lots and garages
• Transportation facilities
• Lobbies and reception areas
• Industrial facilities
• Building entrances and common areas
• Large indoor spaces
• Outdoor commercial areas

Manufacturer: Axis Communications
Model: AXIS M4337-PLVE
Part Number: 03130-001
Camera Type: Panoramic Network Camera
Resolution: 6 MP
Maximum Resolution: 2464 x 2464
Field of View: 185° horizontal / 185° vertical
Coverage: 180° / 360°
Lens: 1.7 mm stereographic
IR: Built-in OptimizedIR
Video Compression: AV1 / H.264 / H.265
Analytics: AXIS Object Analytics and additional AI-powered analytics
Protection: IP66 / IK10
Operating Temperature: -40°F to 122°F
