AXIS M4216-V 4MP Indoor Varifocal Dome

Description
Detailed Specifications

Description

AXIS M4216-V Dome Camera – 4 MP Indoor Varifocal Dome

The AXIS M4216-V is a compact, discreet 4 MP indoor dome with a varifocal lens and remote zoom and focus. Lightfinder and WDR keep images clear in difficult light, a deep learning processing unit runs AXIS Object Analytics on the edge, and an HDMI output can drive a public-view monitor. Audio and I/O can be added with AXIS T61 Series portcast accessories, and Axis Edge Vault safeguards the device.

Key Specifications

Max video resolution	2304x1728
Max frames per second	25/30
Lens	Varifocal, 3&ndash
Horizontal field of view	100°–45°
Wide dynamic range	WDR, up to 110 dB
Lightfinder	Lightfinder
Min illumination (color)	0.18 lux
Onboard analytics	AXIS Object Analytics (deep learning processing unit)
PoE class	Class 2
IP rating	IP42
Vandal rating	IK08
HDMI output	Yes (HDMI type D)
Operating temperature	0 to 45 °C

Full specifications are listed in the Detailed Specifications tab.

Why Choose the AXIS M4216-V?

4 MP resolution (2304x1728) at up to 25/30 fps
Varifocal lens (3&ndash) with remote zoom and focus, 100°–45° horizontal field of view
Lightfinder and WDR for day, night and mixed light
AXIS Object Analytics on a deep learning processing unit
Axis Edge Vault hardware-based cybersecurity
IP42 and IK08 rated, compact casing that can be repainted
HDMI output for public view monitors; audio and I/O via AXIS T61 Series
Single-cable PoE (Class 2)

Frame the Shot Remotely

The varifocal lens covers 100°–45° horizontally with remote zoom and focus, so installers can set the view from a browser. The camera can be pointed in any direction, including at the wall or ceiling.

Clear Images in Challenging Light

Lightfinder delivers color in low light and WDR (up to 110 dB depending on scene) holds detail when bright and dark areas share the frame.

Analytics on the Edge

A deep learning processing unit runs AXIS Object Analytics to detect and classify humans and vehicles, and AXIS Scene Metadata, AXIS Face Detector and AXIS Live Privacy Shield are included.

HDMI Output and Expandable Audio

An HDMI output (1080p at 25/30 Hz) can feed a public view monitor, and AXIS T61 Series portcast accessories add two-way audio and I/O over the same cable.

Built-In Cybersecurity

Axis Edge Vault provides a secure element (CC EAL 6+), secure boot, signed OS, signed video and an encrypted filesystem, with IEEE 802.1X and HTTPS/TLS for network security.

Typical Applications

Classrooms and offices
Retail floors and checkouts
Lobbies and reception areas
Healthcare waiting areas

Compatible Accessories

Compatible accessories for the AXIS M4216-V. Linked items are available at Affinitech Store; contact us for the others:

Compare AXIS M42 Dome Cameras

Model	Max resolution	Type	Best for
AXIS M4215-V	1920x1080	Indoor 2 MP varifocal dome	Classrooms, retail, offices
AXIS M4215-LV	1920x1080	Indoor 2 MP varifocal dome with IR	Hallways, stairwells, dark rooms
AXIS M4216-V (this camera)	2304x1728	Indoor 4 MP varifocal dome	Classrooms, retail, offices
AXIS M4216-LV	2304x1728	Indoor 4 MP varifocal dome with IR	Hallways, stairwells, dark rooms
AXIS M4218-V	3840x2160	Indoor 4K varifocal dome	Lobbies, retail floors, open offices
AXIS M4218-LV	3840x2160	Indoor 4K varifocal dome with IR	Hallways, stairwells, dark rooms
AXIS M4225-LVE	1920x1080	Outdoor 2 MP AI dome with IR and audio analytics	Entrances, perimeters, parking areas
AXIS M4227-LVE	2592x1944	Outdoor 5 MP AI dome with IR and audio analytics	Entrances, perimeters, parking areas
AXIS M4228-LVE	3840x2160	Outdoor 4K AI dome with IR and audio analytics	Entrances, perimeters, parking areas

Need night vision? See the AXIS M4216-LV with built-in OptimizedIR.

Explore More

Browse the full Dome Cameras collection at Affinitech Store
See more AI-Powered Cameras at Affinitech Store

Frequently Asked Questions About AXIS M4216-V

What resolution does the AXIS M4216-V capture?

Up to 2304x1728 (4 MP) at up to 25/30 fps.

What lens does it have?

Varifocal, 3&ndash with a 100°–45° horizontal and 72°–34° vertical field of view, with remote zoom and focus.

Can it be installed outdoors?

No. It is an indoor camera with IP42 and IK08 ratings.

Does it have built-in IR?

No. For built-in IR, choose the -LV version.

Which analytics are included?

AXIS Live Privacy Shield (16:9 capture mode required), AXIS Object Analytics, AXIS Scene Metadata, AXIS Video Motion Detection, AXIS Face Detector, active tampering alarm.

How is it powered?

Power over Ethernet: PoE IEEE 802.3af/802.3at Type 1 Class 2; typical 2.8 W, max 4.4 W.

What is the minimum light sensitivity?

Color: 0.18 lux at 50 IRE F2.0; B/W: 0.03 lux at 50 IRE F2.0 (with Lightfinder).

Does it support local storage?

Yes, microSD/microSDHC/microSDXC cards, plus recording to network-attached storage (NAS).

Does it have an HDMI output?

Yes, HDMI type D: 1080p (16:9) at 25/30 Hz or 720p (16:9) at 50/60 Hz.

Does it support audio?

Two-way audio and I/O can be added through portcast technology with AXIS T61 Series accessories.

What cybersecurity features are built in?

Axis Edge Vault with a secure element, secure boot, signed OS, signed video and an encrypted filesystem.

What warranty does it have?

A 5-year Axis warranty.

View AllClose

Detailed Specifications

AXIS M4216-V Dome Camera Specifications

Specification	Details
Camera
Image sensor	1/2.7" progressive scan RGB CMOS
Lens	Varifocal, 3–6 mm, F1.9–2.7; remote focus and zoom, fixed iris
Horizontal field of view	100°–45°
Vertical field of view	72°–34°
Day and night	Automatic IR-cut filter
Minimum illumination	Color: 0.18 lux at 50 IRE F2.0 · B/W: 0.03 lux at 50 IRE F2.0 (with Lightfinder)
Shutter speed	1/37500 s to 1/5 s
Camera adjustment	Pan ±180°, tilt -40 to +65°, rotation ±105°; can be directed in any direction and see the wall/ceiling
System on Chip (SoC)
Model	CV25
Memory	1024 MB RAM, 512 MB Flash
Compute capabilities	Deep learning processing unit (DLPU)
Video
Video compression	H.264 (MPEG-4 Part 10/AVC) Main and High Profiles, H.265 (MPEG-H Part 2/HEVC) Main and High Profiles, Motion JPEG
Resolution	2304x1728 to 320x240 (native sensor resolution 5 MP)
Frame rate	Up to 25/30 fps with power line frequency 50/60 Hz in H.264 and H.265 (reduced frame rate in Motion JPEG)
Video streaming	Multiple, individually configurable streams in H.264, H.265 and Motion JPEG; Axis Zipstream in H.264 and H.265; controllable frame rate and bandwidth; VBR/MBR H.264/H.265; low latency mode
Multi-view streaming	Up to 2 individually cropped out view areas in full frame rate
HDMI output	HDMI 1080p (16:9) at 25/30 Hz refresh rate; HDMI 720p (16:9) at 50/60 Hz refresh rate
Image settings	Compression, color, brightness, sharpness, contrast, white balance, exposure control, motion-adaptive exposure, WDR up to 110 dB depending on scene, text and image overlay, mirroring of images, privacy mask; rotation 0°, 90°, 180°, 270°, including Corridor Format
Pan/Tilt/Zoom	Digital PTZ
Audio
Audio input/output	Audio features through portcast technology: two-way audio connectivity, voice enhancer
Network
Network protocols	IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SSH, HDMI, LLDP, CDP, MQTT v3.1.1, Syslog, Link-Local address (ZeroConf)
System Integration
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; one-click cloud connection; ONVIF® Profile G, M, S and T; Session Initiation Protocol (SIP) for integration with Voice over IP (VoIP) systems, peer to peer or integrated with SIP/PBX
Video management systems	Compatible with AXIS Camera Station Edge, AXIS Camera Station Pro, and video management software from Axis’ partners
Event conditions	Device status: above/below/within operating temperature, IP address removed, network lost, new IP address, system ready; edge storage: recording ongoing, storage disruption; I/O: manual trigger, virtual input, digital input via AXIS T61 Audio and I/O Interfaces with portcast technology; MQTT subscribe; scheduled and recurring: scheduled event; video: live stream open
Event actions	MQTT publish; notification: email, HTTP, HTTPS, TCP and SNMP trap; overlay text, zoom preset, day/night mode; pre- and post-alarm video or image buffering for recording or upload; record video: SD card and network share; upload of images or video clips: FTP, SFTP, HTTP, HTTPS, network share and email; external output activation via AXIS T61 Audio and I/O Interfaces with portcast technology
Built-in installation aids	Remote zoom, remote focus
Analytics
Applications included	AXIS Live Privacy Shield (16:9 capture mode required), AXIS Object Analytics, AXIS Scene Metadata, AXIS Video Motion Detection, AXIS Face Detector, active tampering alarm
Applications supported	AXIS People Counter, AXIS Queue Monitor; AXIS Camera Application Platform (ACAP) third-party applications
AXIS Object Analytics	Object classes: humans, vehicles (cars, buses, trucks, bikes) · Scenarios: line crossing, object in area, crossline counting, occupancy in area, time in area · Up to 10 scenarios · Color-coded bounding boxes · Polygon include/exclude areas · Perspective configuration · ONVIF Motion Alarm event
AXIS Scene Metadata	Object classes: humans, faces, vehicles (cars, buses, trucks, bikes), license plates · Object attributes: vehicle color, upper/lower clothing color, confidence, position
Approvals
EMC	EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2; Australia/New Zealand: CISPR 24, CISPR 35, RCM AS/NZS CISPR 32 Class A; Canada: ICES-3(A)/NMB-3(A); Japan: VCCI Class A; Korea: KC KN32 Class A, KC KN35; USA: FCC Part 15 Subpart B Class A
Safety	IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, IS 13252
Environment	IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC/EN 60529 IP42, IEC/EN 62262 IK08
Network	NIST SP500-267
Cybersecurity	ETSI EN 303 645, BSI IT Security Label
Cybersecurity
Edge security	Software: signed OS, brute force delay protection, digest authentication and OAuth 2.0 RFC6749 Client Credential Flow/OpenID Authorization Code Flow for centralized ADFS account management, password protection, AES-XTS-Plain64 256-bit SD card encryption · Hardware: Axis Edge Vault cybersecurity platform; secure element (CC EAL 6+), system-on-chip security (TEE), Axis device ID, secure keystore, signed video, secure boot, encrypted filesystem (AES-XTS-Plain64 256-bit)
Network security	IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2), IEEE 802.1AE (MACsec PSK/EAP-TLS), IEEE 802.1AR, HTTPS/HSTS, TLS v1.2/v1.3, Network Time Security (NTS), X.509 Certificate PKI, host-based firewall
General
Casing	IP42 water- and dust-resistant, IK08 impact-resistant, polycarbonate and aluminum casing with hard-coated dome; encapsulated electronics; color white NCS S 1002-B; can be repainted (contact your Axis partner)
Power	PoE IEEE 802.3af/802.3at Type 1 Class 2; typical 2.8 W, max 4.4 W
Connectors	RJ45 10BASE-T/100BASE-TX PoE; HDMI type D; audio and I/O connectivity via portcast technology
Storage	microSD/microSDHC/microSDXC card with SD card encryption (AES-XTS-Plain64 256-bit); recording to network-attached storage (NAS)
Operating conditions	0 °C to 45 °C (32 °F to 113 °F); humidity 10–85% RH (non-condensing)
Storage conditions	-40 °C to 65 °C (-40 °F to 149 °F); humidity 5–95% RH (non-condensing)
Dimensions	Height 71 mm (2.8 in), ø 121 mm (4.76 in)
Weight	350 g (0.77 lb)
Included accessories	Installation guide, Windows® decoder 1-user license
Optional accessories	AXIS TM3207 Recessed Mount, AXIS T94C01L Recessed Mount, AXIS T94C01U Universal Mount, AXIS T94C01M J-Box/Gang Box Plate, AXIS M42 Casing A Black 4P, AXIS M42 Smoked Dome A 4P, AXIS T91A33 Lighting Track Mount, AXIS T91A23 Tile Grid Ceiling Mount, AXIS TM3101 Pendant Wall Mount, AXIS Surveillance Cards
Languages	English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Traditional Chinese, Dutch, Czech, Swedish, Finnish, Turkish, Thai, Vietnamese
Warranty	5-year warranty
