AXIS M1055-L 2MP Indoor AI Box Camera with IR, 02349-001
Description
AXIS M1055-L 2 MP Indoor AI Box Camera with IR
The AXIS M1055-L is a small, budget-friendly indoor box camera that records HDTV 1080p across a 103° view, with built-in OptimizedIR and a deep learning processing unit for AXIS Object Analytics. Privacy is designed in: a tally LED shows when video is streaming or recording, AXIS Live Privacy Shield masks people in live view, and Axis Edge Vault protects the device identity. An I/O port for an alarm button and low PoE Class 2 power make it a fit for small offices, shops and classrooms.
Key Specifications
| Max video resolution | 1920x1080 (HDTV 1080p) |
| Max frames per second | Up to 25/30 fps (50/60 Hz) |
| Lens | Fixed 3.16 mm, F2.0, IR corrected |
| Horizontal field of view | 103° |
| Wide dynamic range | WDR up to 120 dB depending on scene |
| Min illumination (color) | 0.18 lux at 50 IRE, F2.0 |
| Built-in IR | OptimizedIR, 850 nm, 18 m (59 ft) or more depending on scene |
| Onboard analytics | AXIS Object Analytics (humans, vehicles) on a deep learning processing unit |
| I/O | 1 alarm input, 1 output |
| PoE class | IEEE 802.3af/802.3at Type 1 Class 2 |
| Operating temperature | 0 °C to 35 °C (32 °F to 95 °F) |
Full specifications are listed in the Detailed Specifications tab.
Why Choose the AXIS M1055-L?
- HDTV 1080p at up to 25/30 fps with a 103° horizontal view
- Built-in OptimizedIR, 18 m (59 ft) or more depending on scene
- Deep learning processing unit with AXIS Object Analytics and AXIS Scene Metadata
- Privacy features: tally LED and AXIS Live Privacy Shield
- Axis Edge Vault with CC EAL 6+ secure element and signed video
- I/O port for accessories such as alarm buttons
- Low-power PoE Class 2 (max 4.3 W) on a single cable
- microSD card slot with encryption for local recording
Clear 1080p Video, Day and Night
A 1/2.9″ sensor and fixed 3.16 mm, F2.0 IR-corrected lens record 1920x1080 at up to 25/30 fps. WDR up to 120 dB keeps detail when windows and dark corners share the frame, and color is maintained down to 0.18 lux. In darkness the infrared-cut filter switches out and OptimizedIR with an 850 nm LED lights the room up to 18 m (59 ft) or more, depending on the scene.
Corner-to-Corner Coverage
The 103° horizontal and 55° vertical field of view lets one camera mounted in a corner take in most of a small room. Rotation including Corridor Format, exposure zones and polygon privacy masks help tailor the image.
AI Analytics on the Edge
The CV25 chip with a deep learning processing unit runs AXIS Object Analytics, which detects and classifies humans and vehicles in up to 10 scenarios, including line crossing, object in area, crossline counting and occupancy in area; Axis also highlights time in area for loitering or dwell-time alerts. AXIS Scene Metadata, AXIS Video Motion Detection, AXIS Live Privacy Shield and active tampering alarm are included, and MQTT publish and subscribe link events to other systems.
Privacy and Cybersecurity by Design
A tally LED signals when video is streaming or recording, and AXIS Live Privacy Shield masks people in real time. Axis Edge Vault adds a CC EAL 6+ secure element, TEE, Axis device ID, signed video, secure boot and an encrypted filesystem, while signed OS, IEEE 802.1X, MACsec, HTTPS/HSTS and TLS v1.2/v1.3 secure the network connection.
Small, Simple Installation
At 105 x 60 x 93 mm and 137 g, the camera mounts on a wall or in a corner with the included wall mount. One PoE cable (Class 2, typical 2.2 W) powers it, a 4-pin terminal block connects 1 alarm input and 1 output, and ONVIF Profiles G, M, S and T plus VAPIX connect it to AXIS Camera Station Edge, Pro and 5 or partner VMS.
Typical Applications
- Small offices and reception areas
- Convenience and specialty stores
- Classrooms and school offices
- Break rooms and storage rooms
- Dark rooms and after-hours spaces
Compatible Accessories
Compatible accessories for the AXIS M1055-L, available at Affinitech Store:
Compare AXIS M10 Box Cameras
| Model | Max resolution | Type | Best for |
|---|---|---|---|
| AXIS M1055-L (this camera) | 1920x1080 | Indoor 2 MP AI box, IR, I/O | Small offices, shops, corners |
| AXIS M1075-L | 1920x1080 | Indoor 2 MP AI box, IR, two-way audio, PIR (discontinued) | Reception desks, small stores |
| AXIS M1075-L Mk II | 1920x1080 | Indoor 2 MP AI box, IR, two-way audio, audio analytics | Classrooms, care facilities, small stores |
Need audio? See the AXIS M1075-L Mk II (03280-001) with built-in microphones, speaker and AXIS Audio Analytics.
Explore More
- Browse the full Box Cameras collection at Affinitech Store
- See compact Cube Cameras at Affinitech Store
- Shop IR Cameras for night coverage
- Explore AI Cameras with onboard analytics at Affinitech Store
Frequently Asked Questions About AXIS M1055-L
What resolution does the AXIS M1055-L record?
HDTV 1080p: 1920x1080 down to 640x360 in 16:9, or 1280x960 down to 320x240 in 4:3, at up to 25/30 fps in H.264 and H.265.
What is its field of view?
103° horizontal and 55° vertical from a fixed 3.16 mm, F2.0 IR-corrected lens, wide enough to cover a room from a corner.
Can it see in the dark?
Yes. OptimizedIR with an 850 nm LED reaches 18 m (59 ft) or more depending on the scene, down to 0 lux.
What is the minimum illumination?
Color 0.18 lux and B/W 0.04 lux at 50 IRE, F2.0; 0 lux with IR on.
Which analytics are included?
AXIS Object Analytics, AXIS Scene Metadata, AXIS Video Motion Detection, AXIS Live Privacy Shield and active tampering alarm, running on a deep learning processing unit.
Does it record audio?
No. The AXIS M1055-L has no audio. For built-in microphones and a speaker, see the AXIS M1075-L Mk II.
Does it have I/O?
Yes. A 4-pin terminal block provides 1 alarm input and 1 output (12 V DC, max 25 mA), for example for a panic button.
How is it powered?
Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 2, typical 2.2 W and max 4.3 W.
Can it store video locally?
Yes. It supports microSD, microSDHC and microSDXC cards with AES-XTS-Plain64 256bit encryption.
Where can it be installed?
Indoors, on walls or in corners with the included wall mount, at 0 °C to 35 °C (32 °F to 95 °F) and 10-85% RH, non-condensing.
What cybersecurity features does it have?
Axis Edge Vault with a CC EAL 6+ secure element, TEE, Axis device ID, secure keystore, signed video, secure boot and encrypted filesystem, plus signed OS, IEEE 802.1X, MACsec and TLS v1.2/v1.3.
What warranty does it have?
A 5-year Axis warranty.
Videos
View AllCloseDetailed Specifications
AXIS M1055-L Box Camera Specifications
| Specification | Details |
|---|---|
| Camera | |
| Image sensor | 1/2.9″ progressive scan RGB CMOS |
| Lens | Fixed focal length 3.16 mm, F2.0, fixed iris, IR corrected Horizontal field of view: 103° Vertical field of view: 55° |
| Day and night | Automatically removable infrared-cut filter |
| Minimum illumination | Color: 0.18 lux at 50 IRE, F2.0 B/W: 0.04 lux at 50 IRE, F2.0 0 lux with IR illumination on |
| Shutter speed | 1/19000 s to 1/5 s |
| System on chip (SoC) | |
| Model | CV25 |
| Memory | 1024 MB RAM, 512 MB Flash |
| Compute capabilities | Deep learning processing unit (DLPU) |
| Video | |
| Video compression | H.264 (MPEG-4 Part 10/AVC) Main and High Profiles H.265 (MPEG-H Part 2/HEVC) Main Profile Motion JPEG |
| Resolution | 1280x960 to 320x240 (4:3) 1920x1080 to 640x360 (16:9) |
| Frame rate | Up to 25/30 fps (50/60 Hz) in H.264 and H.265 in all resolutions (reduced frame rate in Motion JPEG) |
| Video streaming | Multiple, individually configurable streams in H.264, H.265 and Motion JPEG Axis Zipstream technology in H.264 and H.265 Controllable frame rate and bandwidth VBR/ABR/MBR H.264/H.265 |
| Image settings | Saturation, contrast, brightness, sharpness, WDR: up to 120 dB depending on scene, white balance, day/night threshold, exposure mode, exposure zones, compression, rotation: 0°, 90°, 180°, 270° including Corridor Format, mirroring, dynamic overlay, polygon privacy masks |
| Network | |
| Network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, HTTP/2, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, NTP, PTP, NTS, RTSP, RTCP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, SSH, LLDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| System integration | |
| Application Programming Interface | Open API for software integration, including VAPIX®, metadata and AXIS Camera Application Platform (ACAP) One-click cloud connection ONVIF® Profile G, ONVIF® Profile M, ONVIF® Profile S and ONVIF® Profile T |
| Event conditions | Device status: above operating temperature, above or below operating temperature, below operating temperature, IP address removed, live stream active, network lost, new IP address, system ready, within operating temperature Edge storage: recording ongoing, storage disruption, storage health issues detected I/O: digital input is active, digital output is active, manual trigger, virtual input is active MQTT: subscribe Scheduled and recurring: schedule Video: average bitrate degradation, day-night mode, tampering |
| Event actions | Day-night mode: use day-night mode while the rule is active I/O: toggle I/O once, toggle I/O while the rule is active Illumination: use lights, use lights while the rule is active Images: FTP, HTTP, HTTPS, SFTP, email and network share MQTT: publish Notification: HTTP, HTTPS, TCP and email Overlay text: use overlay text, use overlay text while the rule is active Recordings: record video, record video while the rule is active SNMP trap messages: send, send while the rule is active Status LED: flash status LED, flash status LED while the rule is active Video clips: FTP, HTTP, HTTPS, SFTP, email and network share WDR mode: set WDR mode, set WDR mode while the rule is active |
| Analytics | |
| Applications | Included: AXIS Object Analytics, AXIS Scene Metadata, AXIS Video Motion Detection, AXIS Live Privacy Shield, active tampering alarm Supported: AXIS Camera Application Platform enabling installation of third-party applications |
| AXIS Object Analytics | Object classes: humans, vehicles (types: cars, buses, trucks, bikes) Scenarios: line crossing, object in area, crossline counting, occupancy in area Up to 10 scenarios Other features: triggered objects visualized with color-coded bounding boxes Polygon include/exclude areas Perspective configuration ONVIF Motion Alarm event |
| AXIS Scene Metadata | Object classes: humans, faces, vehicles (types: cars, buses, trucks, bikes), license plates Object attributes: vehicle color, upper/lower clothing color, confidence, position |
| Approvals | |
| EMC | EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2 Australia/New Zealand: RCM AS/NZS CISPR 32 Class A Canada: ICES-3(A)/NMB-3(A) Japan: VCCI Class A Korea: KS C 9832 Class A, KS C 9835 USA: FCC Part 15 Subpart B Class A |
| Safety | CAN/CSA C22.2 No. 62368-1 ed. 3, IEC/EN/UL 62368-1 ed. 3, IEC 62471 (exempt), IS 13252 |
| Environment | IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78 |
| Network | NIST SP500-267 |
| Cybersecurity | ETSI EN 303 645, BSI IT Security Label |
| Cybersecurity | |
| Edge security | Software: signed OS, brute force delay protection, digest authentication and OAuth 2.0 RFC6749 Client Credential Flow/OpenID Authorization Code Flow for centralized ADFS account management, password protection, AES-XTS-Plain64 256bit SD card encryption Hardware: Axis Edge Vault cybersecurity platform, secure element (CC EAL 6+), system-on-chip security (TEE), Axis device ID, secure keystore, signed video, secure boot, encrypted filesystem (AES-XTS-Plain64 256bit) |
| Network security | IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2), IEEE 802.1AE (MACsec PSK/EAP-TLS), IEEE 802.1AR, HTTPS/HSTS, TLS v1.2/v1.3, Network Time Security (NTS), X.509 Certificate PKI, host-based firewall |
| Documentation | AXIS OS Hardening Guide, Axis Vulnerability Management Policy, Axis Security Development Model, AXIS OS Software Bill of Material (SBOM) |
| General | |
| Casing | Aluminum and plastic Color: white NCS S 1002-B |
| Sustainability | PVC free, BFR/CFR free, 70% recycled plastics |
| Power | Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 2 Typical 2.2 W, max 4.3 W |
| Connectors | Shielded RJ45 10BASE-T/100BASE-TX PoE I/O: 4-pin 2.5 mm terminal block for 1 alarm input and 1 output (12 V DC output, max load 25 mA) |
| IR illumination | OptimizedIR with power-efficient, long-life 850 nm IR LED Range of reach 18 m (59 ft) or more depending on the scene |
| Storage | Support for microSD/microSDHC/microSDXC card Support for SD card encryption (AES-XTS-Plain64 256bit) |
| Operating conditions | 0 °C to 35 °C (32 °F to 95 °F) Humidity 10–85% RH (non-condensing) |
| Storage conditions | -40 °C to 65 °C (-40 °F to 149 °F) Humidity 5–95% RH (non-condensing) |
| Dimensions | 105 x 60 x 93 mm (4.1 x 2.4 x 3.7 in) |
| Weight | 137 g (0.30 lb) |
| Included accessories | Installation guide, Windows® decoder 1-user license, wall mount, terminal block connector |
| Optional accessories | AXIS T8415 Wireless Installation Tool, AXIS Surveillance Cards |
| Video management systems | Compatible with AXIS Camera Station Edge, AXIS Camera Station Pro, AXIS Camera Station 5, and video management software from Axis’ partners |
| Languages | English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Polish, Traditional Chinese, Dutch, Czech, Swedish, Finnish, Turkish, Thai, Vietnamese |
| Warranty | 5-year warranty |
