2N NVT PL-08 8-Port 2-Wire to Ethernet Switch Kit, 02318-001
Description
2N NVT PL-08 8-Port 2-Wire Ethernet Switch with 2 Adapters
The 2N NVT PL-08 kit is a two-wire to Ethernet converter built around an 8-port switch unit and two NVT Phybridge adapters. It is meant for sites where only old two-conductor cable is available and networked devices still need to be connected. Extra adapters are ordered separately, either as the six-pack 02319-001 or one at a time as 03520-001.
Key Specifications
| Part number | 02318-001 |
| Type | Two-wire to Ethernet converter (NVT Phybridge PL-08) |
| Switch unit | 8-port long-reach PoE switch with 2 x 100 Mbps uplink ports |
| Reach | Up to 1,200 ft (365 m) over single-pair UTP |
| Speed and PoE | 10 Mbps symmetrical (full duplex), PoE up to 15 W |
| Adapters in the box | 2 |
| More adapters | 02319-001 (6-pack) or 03520-001 (single) |
| EAN | 8595159517599 |
| Shipping weight | 2.6 lb |
Full specifications are listed in the Detailed Specifications tab.
What You Get
- One 8-port NVT PL-08 switch unit.
- Two NVT adapters for the device end of each two-wire run.
- Room to grow with the 02319-001 six-pack or 03520-001 single adapter, ordered separately.
Related Products
Related 2N products, in the same two-wire family:
- 2N NVT PL-08 Pack of 6 Adapters, 02319-001
- 2N NVT PL-08 Single Adapter, 03520-001
- 2N Clip 2wire-IP Switch with 6 Powered 2-Wire Ports
Explore More
- See the full Access Control collection
Frequently Asked Questions About 2N NVT PL-08 Switch
What is the 2N NVT PL-08 kit?
A two-wire to Ethernet converter set: an 8-port switch unit plus two adapters, supplied by 2N and made by NVT Phybridge.
What is in the box?
The switch unit and two adapters. Product data describes the package as the 8-port unit with 2 adapters.
How do I add more adapters?
Order the six-pack (02319-001) or a single adapter (03520-001). Both are listed as compatible with this switch.
Is this the same as the 2N Clip 2wire-IP Switch?
No. The Clip 2wire-IP Switch (03450-001) is a separate 2N product for Clip 2wire-IP indoor stations. The NVT PL-08 is a different, NVT-built switch.
What cable distance does it support?
The distributor listing for this kit gives a reach of up to 1,200 ft (365 m) over single-pair UTP at 10 Mbps full duplex, with PoE up to 15 W. Real runs depend on the cable and the load, so ask our team if you are close to the limit.
Which 2N devices can connect through it?
Product data does not name specific 2N models, so confirm the device you plan to connect with our team before ordering.
Detailed Specifications
2N NVT PL-08 Switch Specifications
| Specification | Details |
|---|---|
| Product | |
| Name | 2N NVT PL-08 Switch with 2 Adapters |
| Part number | 02318-001 |
| Manufacturer | NVT Phybridge, supplied by 2N |
| Key Specifications | |
| Function | Converts two-wire cabling to Ethernet |
| Switch unit | 8-port long-reach PoE switch, 2 x 100 Mbps uplink ports |
| Reach | Up to 1,200 ft (365 m) over single-pair UTP |
| Speed | 10 Mbps symmetrical (full duplex) |
| PoE | Up to 15 W |
| Adapters included | 2 |
| Expansion | |
| Six-pack of adapters | 02319-001 |
| Single adapter | 03520-001 |
| Parts Included | |
| Contents | 1 x 8-port switch unit, 2 x adapters |
| EAN | 8595159517599 |
| Shipping | |
| Shipping weight | 2.6 lb |
| Shipping dimensions (W x D x H) | 2.8 x 7.91 x 8.31 in |
