Hanwha Vision QNE-C8013RL 5MP Dual Light Outdoor Flat-Eye

Name: Hanwha Vision QNE-C8013RL 5MP Dual Light Outdoor Flat-Eye Camera
Brand: Hanwha Vision America
SKU: QNE-C8013RL
Price: 468 USD
Availability: InStock

Description
Detailed Specifications

Description

Hanwha Vision QNE-C8013RL – 5MP Dual Light Outdoor Flat-Eye

The Hanwha Vision QNE-C8013RL is a 5MP Dual Light Outdoor Flat-Eye built for entrances, building perimeters and parking areas. Wisenet Q network outdoor flat-eye camera, 5MP @ 30fps, 3mm fixed focal lens (H: 97° / V: 53°), triple codec H.265/H.264/MJPEG with Wisestream III, 120dB WDR, Dual Light – White LED range 30m (98ft), IR viewable length 30m (98ft), Motion Detection based on AI engine, Classified object type: Person/Vehicle (vehicle type: car/bus/truck/motorcycle/bicycle); IVA events based on AI engine: Virtual line (Crossing/Direction), Virtual area (Loitering/Intrusion/Enter/Exit/(Dis)Appear), defocus detection, hallway View, built-in SD card slot (1x256GB), video analytics, IP66/IP67, IK10, PoE, Operating temperature -40°C~+60°C(-40°F ~ +140°F) white color. OnCloud Compatible.

Key Specifications

Max video resolution	2592x1944 (5MP)
Max frames per second	30fps/25fps(60Hz/50Hz)
Image sensor	1/2.8" CMOS
Focal length / lens	3.0 mm
Horizontal field of view	97°
Wide dynamic range	120 dB
Min illumination (color)	0.022 lux
Built-in IR	30m(98.42ft)
Onboard AI (object classes)	Person, Vehicle
Power	PoE(IEEE802.3af, Class3) · Max. 10.0W, typical 4.5W
IP / vandal rating	IP66, IP67, IK10
Operating temperature	-40°C~+60°C(-40°F~+140°F)

Full specifications are listed in the Detailed Specifications tab.

Why Choose the Hanwha Vision QNE-C8013RL?

5MP 2592x1944 video at up to 30fps/25fps
3.0 mm lens and a 97° horizontal view
120 dB WDR for bright and backlit scenes
Built-in IR: 30m(98.42ft)
AI object classification: Person, Vehicle
Built-in cybersecurity: Encrypted firmware, Secure boot, Signed firmware
IP66, IP67, IK10 rated housing
Power: PoE(IEEE802.3af, Class3)

Clear Video Day and Night

The QNE-C8013RL captures color video down to 0.022 lux; its built-in IR reaches 30m(98.42ft); 120 dB WDR keeps detail in scenes with bright and dark areas.

Coverage and Resolution

A 3.0 mm lens covers a 97° horizontal field of view; per Hanwha Vision DORI figures, it can identify a person at 4.6m(15.05ft); resolution is up to 2592x1944 at 30fps/25fps(60Hz/50Hz).

AI Analytics on the Edge

The onboard AI engine classifies Person, Vehicle; AI events include Object detection, Virtual line(Crossing/Direction), Virtual area(Loitering/Intrusion/Enter/Exit), Motion detection; business intelligence features include People counting, Queue management, Heatmap, Vehicle counting.

Built-In Cybersecurity

Security features include firmware protection: Encrypted firmware, Secure boot, Signed firmware; IEEE 802.1X network authentication.

Installation and Integration

Key installation details: power input: PoE(IEEE802.3af, Class3) (Max. 10.0W, typical 4.5W); operating temperature: -40°C~+60°C(-40°F~+140°F); ratings: IP66, IP67, IK10; edge storage: Max. 256GB x 1slot; compression: H.265: Main, H.264: Main/High, MJPEG.

Typical Applications

Building entrances
Building perimeters
Parking areas
Walkways

Explore More

Browse Dome Cameras at Affinitech Store
Browse Outdoor Cameras at Affinitech Store
Browse IR Cameras at Affinitech Store
Shop all Hanwha Vision products at Affinitech Store

Frequently Asked Questions About Hanwha Vision QNE-C8013RL

What resolution does the Hanwha Vision QNE-C8013RL capture?

Up to 2592x1944 (5MP) at 30fps/25fps(60Hz/50Hz).

What lens does it use?

3.0 mm; horizontal field of view 97°.

Does it see in the dark?

Yes. Built-in IR reaches 30m(98.42ft).

Can it be installed outdoors?

Yes. It is rated IP66, IP67, IK10 and operates from -40°C~+60°C(-40°F~+140°F).

What can the AI analytics detect?

It classifies Person, Vehicle; AI events include Object detection, Virtual line(Crossing/Direction), Virtual area(Loitering/Intrusion/Enter/Exit), Motion detection.

How is it powered?

PoE(IEEE802.3af, Class3) (Max. 10.0W, typical 4.5W).

What video compression does it support?

H.265: Main, H.264: Main/High, MJPEG.

Does it support onboard storage?

Yes: Max. 256GB x 1slot.

What cybersecurity features are built in?

Encrypted firmware, Secure boot, Signed firmware.

Is it ONVIF compliant?

Yes, ONVIF Profile S, G, T, M.

View AllClose

Detailed Specifications

Hanwha Vision QNE-C8013RL Specifications

Specification	Details
Video
Imaging Device - Size	1/2.8"
Imaging Device - Type	CMOS
Resolution	2592x1944, 2560x1440, 1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
Max. Framerate - H.265/H.264	30fps/25fps(60Hz/50Hz)
Max. Framerate - MJPEG	30fps(@5MP Max. 5fps)
Min. Illumination (Lux) - Color(1/30sec, 30IRE)	0.022
Min. Illumination (Lux) - BW(1/30sec, 30IRE)	0.0022
Lens
Focal Length (mm)	3.0
Max Aperture Ratio (F number) - Wide	1.2
Angular Field of View - Horizontal	97°
Angular Field of View - Vertical	71°
Angular Field of View - Diagonal	130°
Min. Object Distance	2.0m(6.56ft)
Focus Control	Fixed
Lens Type	Fixed iris
Mount Type	M12
Pan / Tilt / Rotate
Pan / Tilt / Rotate Range - Pan	0°~350°
Pan / Tilt / Rotate Range - Tilt	0°~75°
Pan / Tilt / Rotate Range - Rotate	0°~360°
Operational
Day & Night	Auto(ICR)
Backlight Compensation	BLC, WDR, SSDR
Wide Dynamic Range (dB)	120
Digital Noise Reduction	WiseNRⅡ(Based on AI engine), SSNRⅤ
Motion Detection - Quantity	8ea
Motion Detection - Shape	8point Polygonal zones
Privacy Masking - Quantity	32ea
Privacy Masking - Shape	4point Quadrangle zones
Privacy Masking - Color / Option	Gray, Green, Red, Blue, Black, White, Mosaic
Privacy Masking - Dynamic Privacy Masking: Color / Option	Mosaic
Gain Control	Low, Middle, High
White Balance	ATW, AWC, Manual, Indoor, Outdoor
LDC	Support
Electronic Shutter - Mode	Minimum, Maximum, Anti flicker, Prefer shutter control(Based on AI engine)
Electronic Shutter - Speed Range	1/5~1/25,000sec
Video Rotation	Flip, Mirror, Hallway view(90°/270°)
Alarm Triggers	Analytics, Network disconnect, MQTT subscription
Alarm Events When Alarm Trigger Occurred	File upload(image): e-mail/FTP, Notification: e-mail, Recording: SD/SDHC/SDXC or NAS recording at event triggers, Handover: PTZ preset, send message by HTTP/HTTPS/TCP, MQTT: publication, Light alarm
Light Type	Warm color, IR LED
Light Viewable Length - Warm Light	30m(98.42ft)
Light Viewable Length - IR	30m(98.42ft)
IR Wavelength	850nm
Analytics
Classified Object Type	Person, Vehicle
Attributes - Person	Upper/Lower clothes color
Attributes - Vehicle	Type(car, bus, truck, motorcycle, bicycle), Color
Thumbnail	BestShot
Analytics Events - Based on AI Engine	Object detection, Virtual line(Crossing/Direction), Virtual area(Loitering/Intrusion/Enter/Exit), Motion detection
Analytics Events - Normal	Defocus detection, Tampering, Virtual area(Appear/Disappear)
Business Intelligence - Based on AI Engine	People counting, Queue management, Heatmap, Vehicle counting
Network
Ethernet	RJ-45(10/100BASE-T)
Video Compression	H.265: Main, H.264: Main/High, MJPEG
Smart Codec	Manual, WiseStreamⅢ
Bitrate Control	H.265/H.264: CBR or VBR, MJPEG: VBR
Streaming - Unicast	Up to 20 users
Streaming - Multicast	Support
Streaming - Multiple Streaming	Up to 5 profiles
Protocol	IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SFTP, SMTP, ICMP, IGMPv2, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP(TCP, UDP Unicast), MQTT
Application Programming Interface - ONVIF	S, G, T, M
Application Programming Interface - Others	SUNAPI(HTTP API), Hanwha Vision Open Platform
Direct Cloud Connection	Support
Security
OS / Firmware Protect	Encrypted firmware, Secure boot, Signed firmware
User authentication	Digest authentication, Prevent brute-force attack
Network authentication	IEEE 802.1X(EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2)
Secure Communication	HTTPS, WSS(WebSocket Secure), SRTP
Access Control	IP-based access control
Data Protect	Encryption credentials, Encrypt compress for live recording file export
Audit	Access / System / Event Log management
Device ID	Device certificate(Hanwha Vision Root CA)
Secure Storage	SDcard partition encrypt(AES-256)
General
Memory - RAM	2GB
Memory - Flash	1GB
Edge Storage - Micro SD/SDHC/SDXC	Max. 256GB x 1slot
Edge Storage(OnCloud) - Micro SD/SDHC/SDXC	Max. 1TB x 1slot *Hanwha Vision branded microSD cards have been certified and recommended for OnCloud edge recording.
Environmental & Electrical
Operating Condition - Temperature	-40°C~+60°C(-40°F~+140°F)
Operating Condition - Humidity	0~100% RH(condensing)
Operating Condition - Others	Start up should be done at above -30°C, Humidity control with AIR vent
Storage Condition - Temperature	-50°C~+60°C(-58°F~+140°F)
Storage Condition - Humidity	0~95% RH(non-condensing)
Input Voltage	PoE(IEEE802.3af, Class3)
Power Consumption - PoE	Max. 10.0W, typical 4.5W
Mechanical
Color	White
Material	Aluminum
RAL Code	RAL9003
Product Dimensions	ø140.0x99.6mm(ø5.51x3.92")
Product Weight	790g(1.74lb)
Compatible Gang Box	Single, Double, 4" Octagon
Certifications & Standards
EMC	FCC 47 CFR 15 Subpart B Class A, ICES-3(A)/NMB-3(A), CE/UKCA - EN55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3, VCCI CISPR 32 Class A, RCM AS-NZS CISPR 32 Class A
Safety	UL 62368-1, CAN/CSA C22.2 NO. 62368-1, IEC 62471
Environment	IEC/EN 63000, IEC 60529 IP66, IEC 60529 IP67, IEC 62262 IK10
DORI (EN62676-4 standard)
Detect (25PPM/ 8PPF) - Wide	45.9m(150.49ft)
Observe (63PPM/ 19PPF) - Wide	18.3m(60.19ft)
Recognize (125PPM/ 38PPF) - Wide	9.2m(30.09ft)
Identify (250PPM/ 76PPF) - Wide	4.6m(15.05ft)
