Hanwha Techwin 6MP IR Indoor Dome AI Camera, XND-8093RV

Video

Imaging Device

1/1.8" progressive CMOS

Resolution

3328x1872, 3072x1728, 2592x1944, 2688x1520, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240

Max. Framerate

H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 15fps/12fps(60Hz/50Hz)

Min. Illumination

Color: 0.04Lux(F1.3, 1/30sec, 30IRE) B/W : 0.004Lux(F1.3, 1/30sec, 30IRE), 0Lux(IR LED on)

Video Out

USB: Micro USB Type B, 1280x720 for installation

Lens

Focal Length (Zoom Ratio)

4.4~9.3mm(2.1x) motorized varifocal

Max. Aperture Ratio

F1.3(Wide) ~ F2.15(Tele)

Angular Field of View

H : 112.1°(Wide)~47.5°(Tele) V : 58.0°(Wide)~26.6°(Tele) D : 137.5°(Wide)~54.6°(Tele)

Min. Object Distance

0.5m(1.64ft)

Focus Control

Simple focus, Manual

Lens Type

P-iris(IR corrected)

Pan / Tilt / Rotate

Pan / Tilt / Rotate Range

0°~360° / -45°~75° / 0°~355°

Operational

Camera Title

Displayed up to 85 characters

Day & Night

Auto(ICR)

Backlight Compensation

BLC, HLC, WDR, SSDR

Wide Dynamic Range

extremeWDR (120dB)

Digital Noise Reduction

WiseNRⅡ(Based on AI engine), SSNRⅤ

Digital Image Stabilization

Support(built-in gyro sensor)

Defog

Support

Motion Detection

8ea, 8point Polygonal zones

Privacy Masking

32ea, Quadrangle zones - Color : Gray, Green, Red, Blue, Black, White - Mosaic

Gain Control

Support

White Balance

ATW / Narrow ATW / AWC / Manual / Indoor / Outdoor

LDC

Support (Fill/stretch mode)

Electronic Shutter Speed

Minimum / Maximum / Anti flicker (2~1/12,000sec) prefer shutter control(Based on AI engine)

Video Rotation

Flip, Mirror, Hallway view(90°/270°)

Analytics

- Analytics events based on AI engine : Object detection (Person/Face/Vehicle(car/bus/truck/motorcycle/bicycle)/License plate), IVA (Virtual line/Area, Enter/Exit, Loitering, direction, Appear/Disappear, intrusion) - Analytics events : Defocus detection, Motion detection, Tampering, Fog detection, Audio detection, Sound classification, Shock detection

Business Intelligence

Based on AI engine : People counting, Queue management, Heatmap

Alarm I/O

2 configurable I/O ports

Alarm Triggers

Analytics, Network disconnect, Alarm input, App event, Time schedule

Alarm Events

When alarm trigger occurred - File upload(image) : e-mail/FTP - Notification : e-mail - Recording : SD/SDHC/SDXC or NAS recording at event triggers - Alarm output - Handover(PTZ preset, Send message by HTTP/HTTPS/TCP) - Audio clip playback

Audio In

Selectable(mic in/line in) Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm

Audio Out

Line out, Max.output level: 1Vrms

IR Viewable Length

WiseIR 40m(131.23ft)

Network

Ethernet

Metal shielded RJ-45(10/100BASE-T)

Video Compression

H.265/H.264: Main/High, MJPEG

Audio Compression

G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz

Smart Codec

Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(Based on AI engine)

Bitrate Control

H.264/H.265: CBR or VBR MJPEG: VBR

Streaming

Unicast(20 users) / Multicast Multiple streaming(Up to 10 profiles, 3 virtual channel support)

Protocol

IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast)

Security

HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2) Device Certificate(Hanwha Techwin Root CA, pre-installed) Secure by default certificate HTPM (Hanwha Trusted platform module) Secure OS/Boot/Storage, Verify firmware forgery CyberSecurity assuarance program UL CAP (UL 2900-1)

Application Programming Interface

ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform

General

Webpage Language

English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,, Portuguese, Czech, Polish, Turkish, Dutch, Greek, Hungarian

Edge Storage

Micro SD/SDHC/SDXC 1slot 512GB

Memory

4GB RAM, 512MB Flash

Environmental & Electrical

Operating Temperature / Humidity

-40°C~+55°C(-40°F ~ +131°F) * Maximum temperature : +60°C (intermittent) * Start up should be done at above -20°C NEMA TS-2 : 74°C 0~95%RH(non-condensing) Humidity control /w GORE vent

Storage Temperature / Humidity

-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH

Certification

IP66/IP67/NEMA4X, IK10

Input Voltage

PoE(IEEE802.3af, Class3), 12VDC

Power Consumption

PoE: Max 12.95W, typical 11.2W 12VDC: Max 13.2W, typical 10.8W

Mechanical

Color / Material

White / Aluminum Hard-coated dome bubble

RAL Code

RAL9003

Product Dimensions / Weight

Ø160x118mm(Ø6.30x4.65"), 1450g(3.20 lb)

DORI (EN62676-4 standard)

Detect (25PPM/ 8PPF)

Wide: 44.8m(147.02ft) / Tele: 151.3m(496.29ft)

Observe (63PPM/ 19PPF)

Wide: 17.9m(58.81ft) / Tele: 60.5m(198.52ft)

Recognize (125PPM/ 38PPF)

Wide: 9.0m(29.4ft) / Tele: 30.3m(99.26ft)

Identify (250PPM/ 76PPF)

Wide: 4.5m(14.7ft) / Tele: 15.1m(49.63ft)
