Hanwha Vision XND-6081VZ 2MP Indoor Dome Camera
Description
Hanwha Vision XND-6081VZ – 2MP Indoor Dome
The Hanwha Vision XND-6081VZ is a 2MP indoor dome camera built for classrooms, retail and offices. It offers 1920x1080 (2MP) video at up to 60 fps and a 2.8 to 12mm lens with a 119.5 to 27.9° horizontal view. It is rated IP52, IK10.
Key Specifications
| Max video resolution | 1920x1080 (2MP) |
| Max frames per second | 60 fps |
| Image sensor | 2 MP 1/2.8" CMOS |
| Focal length / lens | 2.8 to 12mm |
| Horizontal field of view | 119.5 to 27.9° |
| Min illumination (color) | 0.015 lux |
| Power | DC, PoE 802.3af (15 W) |
| IP / vandal rating | IP52, IK10 |
| Operating temperature | -13 to 140°F / -25 to 60°C |
Full specifications are listed in the Detailed Specifications tab.
Why Choose the Hanwha Vision XND-6081VZ?
- 1920x1080 (2MP) video at up to 60 fps
- 2.8 to 12mm lens and a 119.5 to 27.9° horizontal view
- Color video down to 0.015 lux
- IP52, IK10 rated housing
- Power: DC, PoE 802.3af (15 W)
Clear Video Day and Night
The XND-6081VZ captures color video down to 0.015 lux.
Coverage and Resolution
For the XND-6081VZ: a 2.8 to 12mm lens covers a 119.5 to 27.9° horizontal field of view; resolution is up to 1920x1080 (2MP) at 60 fps.
Analytics and Events
Onboard analytics and event features include Defocus Detection, Directional Detection, Fog Detection, Face Detection, Motion Detection, Digital Auto Tracking, Appear.
Built-In Cybersecurity
Security features include Digest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering, User Access Log.
Installation and Integration
Key installation details: power input: DC, PoE 802.3af (15 W); operating temperature: -13 to 140°F / -25 to 60°C; ratings: IP52, IK10; edge storage: Single Slot: microSD/microSDHC/microSDXC [512 GB Maximum]; compression: H.264, H.265, MJPEG; integration: ONVIF Profile G, S.
Typical Applications
- Classrooms and school hallways
- Retail floors and checkout areas
- Offices and lobbies
- Hallways and stairwells
Compare Hanwha Vision X Series Dome Cameras
| Model | Max resolution | Type | Best for |
|---|---|---|---|
| Hanwha Vision XND-6081FZ | 2MP | Indoor dome camera | Classrooms, retail and offices |
| Hanwha Vision XND-6081RF | 2MP | Indoor IR dome camera | Classrooms, retail and offices |
| Hanwha Vision XND-6081V | 2MP | Indoor dome camera | Classrooms, retail and offices |
| Hanwha Vision XND-6081VZ (this camera) | 2MP | Indoor dome camera | Classrooms, retail and offices |
| Hanwha Vision XND-6085V | 2MP | Indoor dome camera | Classrooms, retail and offices |
| Hanwha Vision XND-L6080V | 2MP | Indoor dome camera | Classrooms, retail and offices |
| Hanwha Vision XNV-6081 | 2MP | Outdoor vandal dome camera | Entrances, building perimeters and parking areas |
| Hanwha Vision XNV-6081Z | 2MP | Outdoor vandal dome camera | Entrances, building perimeters and parking areas |
Explore More
- Browse Dome Cameras at Affinitech Store
- Shop all Hanwha Vision products at Affinitech Store
Frequently Asked Questions About Hanwha Vision XND-6081VZ
What resolution does the Hanwha Vision XND-6081VZ capture?
Up to 1920x1080 (2MP) at 60 fps.
What lens does it use?
2.8 to 12mm; horizontal field of view 119.5 to 27.9°.
How does it perform in low light?
Minimum illumination is 0.015 lux (color).
What are its environmental ratings?
It is rated IP52, IK10 and operates from -13 to 140°F / -25 to 60°C.
How is it powered?
DC, PoE 802.3af (15 W).
What video compression does it support?
H.264, H.265, MJPEG.
Does it support onboard storage?
Yes: Single Slot: microSD/microSDHC/microSDXC [512 GB Maximum].
What cybersecurity features are built in?
Digest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering, User Access Log.
Is it ONVIF compliant?
Yes, it supports ONVIF Profile G, S.
What analytics are supported?
Defocus Detection, Directional Detection, Fog Detection, Face Detection, Motion Detection, Digital Auto Tracking, Appear.
What are the dimensions and weight of the Hanwha Vision XND-6081VZ?
Dimensions: ø160x125 mm (ø6.3x4.92 in). Weight: 3.2 lb.
Detailed Specifications
Hanwha Vision XND-6081VZ Specifications
| Specification | Details |
|---|---|
| Camera | |
| Sensor | 2 MP 1/2.8" CMOS |
| Focal Length | 2.8 to 12mm |
| Maximum Aperture | f/1.4 to 3.6 |
| Zoom | Optical: 4.3x; Digital |
| Lens Field of View | Horizontal: 119.5 to 27.9°; Vertical: 62.8 to 15.7°; Diagonal: 142.1 to 32° |
| IR Cut Filter | Mechanical |
| Day/Night | Yes |
| Minimum Illumination | Color: 0.015 Lux; B&W: 0.0015 Lux |
| Shutter Speed | 1/12,000 to 2 Seconds |
| Video | |
| Streaming Resolution | 1920 x 1080 at 60 fps |
| Supported Video Compression | H.264, H.265, MJPEG |
| Multi-View Streaming | Yes, 10 Streams |
| Audio | |
| 1- or 2-Way Audio | Two-Way |
| Audio Formats | AAC, ADPCM, G.711, G.726 |
| Built-In Mic | Yes |
| Built-In Speaker | No |
| External Audio Output | Proprietary |
| Networking | |
| Security | Digest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering, User Access Log |
| Supported Protocols | ARP, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, ICMP, IGMP, IPv4/v6, NTP, ONVIF Profile G, ONVIF Profile S, QoS Layer 3 DiffServ, RTCP, RTP, RTSP, SMTP, SNMP v1/v2c/v3 (MIB-II), SSL/TLS, TCP, UDP, UPnP |
| Application Programming Interface (API) | SUNAPI (HTTP API) |
| Analytics | Defocus Detection, Directional Detection, Fog Detection, Face Detection, Motion Detection, Digital Auto Tracking, Appear, Disappear, Enter, Exit, Loitering, Tampering, Virtual Line, Audio Detection, Sound Classification, Shock Detection |
| Event Trigger | Yes |
| Event Action | Recording, Notification, Alarm |
| System Requirements | |
| Windows OS Support | Windows 7, 8.1, 10 |
| Mac OS Support | macOS 10.12, OS X 10.11, OS X 10.10 |
| Operating Temperature | -13 to 140°F / -25 to 60°C |
| Storage Temperature | -58 to 140°F / -50 to 60°C |
| Operating Humidity | 0 to 89% |
| IP Rating | IP52 |
| IK Rating | IK10 |
| General | |
| Memory | 1024 MB RAM / 256 MB Flash |
| Media/Memory Card Slot | Single Slot: microSD/microSDHC/microSDXC [512 GB Maximum] |
| Pan/Tilt | Manual Pan: 350° (-175 to 175°); Manual Tilt: 85° (0 to 85°) |
| Alarm I/O | 1 / 1 |
| I/O Connections | 1 x RJ45; 1 x Power |
| Supported Languages | Czech; Dutch; English; French; German; Greek; Hungarian; Italian; Japanese; Korean; Polish; Portuguese; Russian; Spanish; Swedish; Traditional Chinese; Turkish |
| Certifications | EAC, UL, as per Manufacturer |
| Internal Storage | None |
| External Storage Options | NAS |
| Power Source | DC, PoE 802.3af (15 W) |
| Power Consumption | PoE: 10 W; DC: 8.5 W |
| Material of Construction | Aluminum |
| Product Dimensions | ø160x125 mm (ø6.3x4.92 in) |
| Product Weight | 3.2 lb |
