Milestone Husky
Milestone 24TB Husky IVO 350R 2-Bay Video Surveillance Station (2 x 12TB)
- SKU:
- HE350R-24TB
- MPN:
- HE350R-24TB
Description
Milestone 24TB Husky IVO 350R 2-Bay Video Surveillance Station (2 x 12TB)
The Husky IVO™ 350R is the ideal “first rack server” product for those who aim to start small in their video installation — yet want the flexibility to grow within their existing IT infrastructure. Your video installation should not only be easy and flexible to set up, but also to manage and run – with-out extra costs or complexity. With the Husky IVO 350R, you get our standard five-year warranty, with seamless single-point support through Milestone and all the benefits of using XProtect as your VMS
Key Features
• Rack-mount unit – ideal for those with an existing IT infrastructure
• Up to 32 TB raw video storage
• Software-based redundancy for increased uptime - Microsoft Windows Storage Spaces (Mirroring)
• Up to 360 Mbps throughput
Detailed Specifications
| Milestone Husky IVO™ 350R Specifications | |
|---|---|
| Hardware Information | |
| Form Factor | Rack mounted 1U |
| CPU | Intel Xeon E-2434 3.4GHz (4 Cores, 8 Threads) |
| RAM | 32 GB DDR5 ECC (2 x 16 GB) |
| Operating System | Windows Server IoT 2022 for Storage Workgroup |
| VMS/OS Storage | 1 x 480 GB SSD (M.2 PCIe NVMe) |
| Hard Drives | 2 x 3.5” |
| Raw Storage (Gross) | 8 / 16 / 24 / 32 TB (Dell Enterprise Grade) |
| RAID | Software RAID (Windows Storage Spaces - Mirroring) |
| Display | 1 x VGA (DB-15, for installation only) |
| Network Interface | 2 x 1 GbE + 1 x 1 GbE iDRAC/Mgmt |
| NAS Archiving | Supported via LAN |
| TPM | TPM 2.0 |
| Remote Management | Yes, iDRAC |
| General Information | |
| Hardware Warranty | 5 years (including HDD), NBD onsite support |
| Dimensions | 482 x 42.8 x 462 mm (19” x 1.7” x 18.5”) |
| Weight | 9.62 kg (21.18 lb) |
| Power Supply | Single 450W, Platinum 100–240 V AC, 50/60 Hz |
| BTU Rating | 1730 BTU/hr (max theoretical) |
| Protections | OVP, OCP, OTP, SCP |
| Environmental | |
| Operating Temperature | 10°C to 35°C (50°F to 95°F) |
| Storage Temperature | -40°C to 65°C (-40°F to 149°F) |
| Humidity | 10% to 85% RH (non-condensing) |
| Regulatory | |
| Model/Type | E104S / E104S001 |
| VMS Compatibility | |
| XProtect VMS | Preloaded, compatible with all XProtect versions. Licenses sold separately. |
| Free VMS Option | Supports XProtect Essential+ with up to 8 cameras |
| Recommended Usage | |
| Camera Support | Up to 50 channels (1080p, 30 FPS, 5-8 Mbps/channel) |
| Local Viewing | Up to 4 channels via Smart Client without affecting recording |
