Video

Imaging Device

1/2.8" CMOS

Resolution

1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360

Max. Framerate

H.265/H.264 : Max. 30fps/25fps(60Hz/50Hz) MJPEG : Max. 10fps

Min. Illumination

Color: 0.03Lux(F2.0, 1/30sec) BW : 0Lux (IR LED on)

Lens

Focal Length (Zoom Ratio)

2.8mm fixed focal

Max. Aperture Ratio

F2.0

Angular Field of View

H: 113.7° / V: 61.5° / D: 134.4°

Min. Object Distance

0.5m(1.64ft)

Focus Control

Fixed

Pan / Tilt / Rotate

Pan / Tilt / Rotate Range

0°~350° / 0°~67° / 0°~355°

Operational

Camera Title

Displayed up to 15 characters

Day & Night

Auto(ICR)

Backlight Compensation

BLC, WDR, SSDR

Wide Dynamic Range

120dB

Digital Noise Reduction

SSNR

Motion Detection

4ea, rectangler zones

Privacy Masking

6ea, rectangular zones

Gain Control

Low / Middle / High

White Balance

ATW / AWC / Manual / Indoor / Outdoor

LDC

Support

Electronic Shutter Speed

Minimum / Maximum / Anti flicker (2~1/12,000sec)

Video Rotation

Flip, Mirror, Hallway view(90˚/270˚)

Analytics

Motion detection, Tampering, Virtual area(Intrusion/Enter/Exit), Virtual line(Crossing/Direction)

Alarm Triggers

Analytics

Alarm Events

File upload via FTP and e-mail Notification via e-mail SD/SDHC recording at event triggers

IR Viewable Length

30m(98.43ft)

Network

Ethernet

RJ-45(10/100BASE-T)

Video Compression

H.265/H.264 : Main/High, MJPEG

Smart Codec

WiseStreamⅡ

Bitrate Control

H.265/H.264: CBR or VBR MJPEG: VBR

Streaming

Unicast(6 users) / Multicast Multiple streaming (Up to 3 profiles)

Protocol

IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour

Security

HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP)

Application Programming Interface

ONVIF Profile S/G/T SUNAPI(HTTP API)

General

Webpage Language

English

Edge Storage

Micro SD/SDHC 1slot 32GB

Memory

512MB RAM, 256MB Flash

Environmental & Electrical

Operating Temperature / Humidity

-30°C ~ +55°C(-22°F ~ +131°F) / Less than 95% RH * Start up should be done at above -20°C(-4°F)

Storage Temperature / Humidity

-30°C ~ +55°C(-22°F ~ +131°F) / Less than 95% RH

Certification

IP66, IK10

Input Voltage

PoE(IEEE802.3af, Class2)

Power Consumption

Max 6.4W, Typical 5.0W

Mechanical

Color / Material

White / Plastic, Aluminum

RAL Code

RAL9003

Product Dimensions / Weight

Ø120.3x91.7mm(Ø4.74x3.61"), 410g

DORI (EN62676-4 standard)

Detect (25PPM/ 8PPF)

25.1m(82.28ft)

Observe (63PPM/ 19PPF)

10.0m(32.91ft)

Recognize (125PPM/ 38PPF)

5.0m(16.46ft)

Identify (250PPM/ 76PPF)

2.5m(8.23ft)
