Video

Imaging Device

1/2.8" CMOS

Resolution

2592x1944, 2560x1440

Max. Framerate

Max. 30fps (@5MP Max. 20fps)

NETD

None

Pixel Size

None

Min. Illumination

Color : 0.06Lux (F1.6, 1/30sec) B/W : 0Lux (IR LED on)

Video Out

BNC: AHD/TVI/CVI/CVBS Selectable

Video Transmission Distance

300m(5C2V Coaxial Cable)

Lens

Focal Length (Zoom Ratio)

3.5mm~10.5mm (3x) motorized varifocal

Max. Aperture Ratio

F1.6

Angular Field of View

H: 82°(Wide)~27°(Tele) V: 60°(Wide)~20°(Tele) D: 105°(Wide)~33°(Tele)

Min. Object Distance

0.8m(2.62ft)

Focus Control

None

Lens Type

None

Mount Type

None

Optional Lens

None

Pan / Tilt / Rotate

Pan / Tilt / Rotate Range

None

Pan Range

None

Pan Speed

None

Tilt Range

None

Tilt Speed

None

Rotate Range

None

Sequence

None

Preset Accuracy

None

Operational

Camera Title

None

Direction Indicator

None

Day & Night

Auto(ICR)

Backlight Compensation

BLC, WDR

Wide Dynamic Range

95dB

Digital Noise Reduction

2D + 3DNR

Digital Image Stabilization

None

Defog

None

Motion Detection

None

Privacy Masking

None

Gain Control

LOW / MIDDLE / HIGH

White Balance

ATW / AWC

LDC

None

Electronic Shutter Speed

AUTO(1/30~1/30,000)

Digital PTZ

None

Video Rotation

MIRROR/V-FLIP/ROTATE

Analytics

None

Business Intelligence

None

Serial Interface

None

Alarm I/O

None

Alarm Triggers

None

Alarm Events

none

Audio In

None

Audio Out

None

IR Viewable Length

25m(82.02ft)

IR Illuminator (Optional)

None

Water Removal

None

Auto Tracking

None

Coaxial Protocol

ACP(AHD Coax Protocol), TCP(TVI Coax Protocol), CCP(CVI Coax Protocol) CVBS: Pelco-C(Coaxitron)

Color Palettes

None

Radiometry

Temperature Detect Range

None

Temperature Accuracy

None

Temperature Detection

None

Additional

None

Network

Ethernet

None

Video Compression

None

Audio Compression

None

Smart Codec

None

Video Quality Adjustment

None

Bitrate Control

None

Streaming

None

Protocol

None

Security

None

Application Programming Interface

None

General

Webpage Language

None

Web Viewer

None

Edge Storage

None

Memory

None

Environmental & Electrical

Operating Temperature / Humidity

-30°C~+55°C(-22°F~+131°F) / 0~90% RH

Storage Temperature / Humidity

-30°C~+60°C(-22°F~+140°F) / 0~90% RH

Certification

IP66, IK10

Input Voltage

12VDC

Power Consumption

Max 7.2W, Typical 5.8W

Mechanical

Color / Material

White / Aluminum / Plastic

RAL Code

None

Product Dimensions / Weight

ø132x103mm(ø5.20"x4.06"), 550g(1.21lb)

Compatible Conduit hole / Gangbox

None

Hanging Mount (Dome)

None

Skin Cover (Dome)

None

Weather Cap (Dome)

None

Power Module

None

Backbox

SBV-A14B

Certifications & Standards

Network

None

EMC

FCC 47 CFR 15 Subpart B Class A ICES-3(A)/NMB-3(A)

Safety

UL 62368-1, CAN/CSA C22.2 NO. 62368-1 IEC 62471

Environmental

None

Video

None
