Hanwha Techwin 2MP IR Bullet AI camera, PNO-A6081R

Video

Imaging Device

1/2" CMOS

Resolution

1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360

Max. Framerate

H.265/H.264: Max. 60/50fps(60Hz/50Hz, AI analytics on), Max. 120/100fps(60Hz/50Hz, AI analytics off) MJPEG: Max. 15fps/12fps(60Hz/50Hz)

NETD

None

Pixel Size

None

Min. Illumination

Color: 0.007Lux(F1.3, 1/30sec, 30IRE) B/W : 0.0007Lux(F1.3, 1/30sec, 30IRE), 0Lux(IR LED on), 30/25fps Color: 0.014Lux(F1.3, 1/60sec, 30IRE) B/W : 0.0014Lux(F1.3, 1/60sec, 30IRE), 0Lux(IR LED on), 60/50fps Color: 0.028Lux(F1.3, 1/120sec,30IRE) B/W : 0.0028Lux(F1.3, 1/120sec, 30IRE), 0Lux(IR LED on), 120/100fps

Video Out

CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation USB: Micro USB Type B, 1280x720 for installation

Video Transmission Distance

None

Lens

Focal Length (Zoom Ratio)

4.38~9.33mm(2.13x) motorized varifocal

Max. Aperture Ratio

F1.3(Wide)~F2.15(Tele)

Angular Field of View

H:103.1°(Wide)~44.5°(Tele) / V:54.2°(Wide)~24.9°(Tele) / D:124°(Wide)~51.1°(Tele)

Min. Object Distance

0.5m(1.64ft)

Focus Control

Simple focus

Lens Type

P iris

Mount Type

None

Optional Lens

None

Pan / Tilt / Rotate

Pan / Tilt / Rotate Range

0˚~360˚ / -45˚~85˚ / 0˚~355˚

Pan Range

None

Pan Speed

None

Tilt Range

None

Tilt Speed

None

Rotate Range

None

Sequence

None

Preset Accuracy

None

Operational

Camera Title

Displayed up to 85 characters

Direction Indicator

None

Day & Night

Auto(ICR)

Backlight Compensation

BLC, WDR, SSDR

Wide Dynamic Range

120dB

Digital Noise Reduction

SSNR, WiseNR Ⅱ(using AI engine)

Digital Image Stabilization

Stabilization Support(built-in gyro sensor)

Defog

None

Motion Detection

8ea, polygonal zones

Privacy Masking

6ea, rectangle zones - Color: Gray/Green/Red/Blue/Black/White

Gain Control

Low / Middle / High

White Balance

ATW / AWC / Manual / Indoor / Outdoor

LDC

Support

Electronic Shutter Speed

Minimum / Maximum / Anti flicker (1/5~1/12,000sec) Auto prefer shutter control based on AI engine

Digital PTZ

None

Video Rotation

Flip, Mirror, Hallway view(90˚/270˚)

Analytics

Classified object type : Person/Face/Vehicle/License plate Attributes : Person(Gender, Color and Bag), Face(Age, Gender, Mask and Glasses), Vehicle(Type:car/bus/truck/motorcycle/bicycle and Color) Support Bestshot per object Analytics events based on AI engine - Object detection, Virtual line*(Crossing/Direction), Virtual area*(Loitering/Intrusion/Enter/Exit), Face mask detection, Digital auto tracking, Social distancing detection Analytics events - Defocus detection, Motion detection, Tampering, Audio detection, Sound classification, Shock detection, Virtual area(Appear/Disappear) *Some of the video analytics only works with people and vehicle detection

Business Intelligence

People counting, Queue management, Heatmap based on AI engine

Serial Interface

None

Alarm I/O

2 configurable I/O ports, DC 12V output(Max. 50mA)

Alarm Triggers

Analytics, Network disconnect, Alarm input

Alarm Events

File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers Alarm output Handover Audio playback

Audio In

Selectable(mic in/line in) Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm

Audio Out

Line out, Max.output level: 1Vrms

IR Viewable Length

40m(131.23ft), Wise IR

IR Illuminator (Optional)

None

Water Removal

None

Auto Tracking

None

Coaxial Protocol

None

Color Palettes

None

Radiometry

Temperature detect range

None

Temperature accuracy

None

Temperature detection

None

Additional

None

Network

Ethernet

Metal shielded RJ-45(10/100/1000 BASE-T)

Video Compression

H.265/H.264: Main/High, MJPEG

Audio Compression

G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz

Smart Codec

Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(using AI engine)

Video Quality Adjustment

H.264/H.265: Target bitrate level control MJPEG: Target bitrate level control

Bitrate Control

H.264/H.265: CBR or VBR MJPEG: VBR

Streaming

Unicast(6 users) / Multicast Multiple streaming(Up to 5 profiles)

Protocol

IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast)

Security

HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) Device Certificate(Hanwha Techwin Root CA) TPM with FIPS 140-2 level2 Secure boot, Verify firmware forgery

Application Programming Interface

ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform

General

Webpage Language

English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek

Web Viewer

None

Edge Storage

Micro SD/SDHC/SDXC 2slots 512GB

Memory

4096MB RAM, 512MB Flash

Environmental & Electrical

Operating Temperature / Humidity

-25°C ~ +50°C (-13°F ~ +122°F) / Less than 90% RH

Storage Temperature / Humidity

-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH

Certification

IP52, IK10, Plenum rate

Input Voltage

PoE+(IEEE802.3at), 12VDC

Power Consumption

PoE+: Max 19.50W, typical 16.00W 12VDC: Max 17.00W, typical 13.50W

Mechanical

Color / Material

White / Aluminum, Hard-coated dome bubble

RAL Code

RAL9003

Product dimensions / weight

Ø205x163mm(8.07x4.92"), Weight : 1.95Kg (4.30lb)

Compatible Conduit hole / Gangbox

None

Hanging mount(Dome)

None

Skin cover(Dome)

None

Weather cap(Dome)

None

Power module

None

Backbox

None

DORI (EN62676-4 standard)

Detect (25PPM/ 8PPF)

Wide: 30.5m(100.03ft) / Tele: 93.9m(307.95ft)

Observe (63PPM/ 19PPF)

Wide: 12.2m(40.01ft) / Tele: 37.5m(123.18ft)

Recognize (125PPM/ 38PPF)

Wide: 6.1m(20.01ft) / Tele: 18.8m(61.59ft)

Identify (250PPM/ 76PPF)

Wide: 3.0m(10.00ft) / Tele: 9.4m(30.79ft)
