AXIS Lens i-CS 3.5-10 mm F1.8 for M1135 and M1137 Mk II, 02638-001
Description
AXIS Lens i-CS 3.5-10 mm F1.8
The AXIS Lens i-CS 3.5-10 mm F1.8 is a varifocal CS-mount i-CS lens for the AXIS M1135/-E Mk II and M1137/-E Mk II box cameras. Three motors give automatic and remote zoom, focus and iris opening, and the lens is IR-corrected so focus holds when the camera moves between day and night mode. It supports sensors up to 1/2.7-inch.
Key Specifications
| Part number | 02638-001 |
| Type | Spare / optional lens (i-CS, CS-mount) |
| Focal length | 3.5-10 mm |
| F-number | F1.8 |
| Mount | CS-mount |
| Image sensor size | Up to 1/2.7-inch |
| IR correction | IR-corrected |
| Compatible with | AXIS M1135/-E Mk II i-CS and M1137/-E Mk II i-CS |
| Shipping weight | 0.26 lb |
Full specifications are listed in the Detailed Specifications tab.
Compatible Cameras
Compatible AXIS box cameras available at Affinitech Store:
- AXIS M1135 Mk II i-CS 2MP Indoor AI Box Camera
- AXIS M1135-E Mk II i-CS 2MP Outdoor AI Box Camera
- AXIS M1137 Mk II i-CS 5MP Indoor AI Box Camera
- AXIS M1137-E Mk II i-CS 5MP Outdoor AI Box Camera
Axis lists the M1135/-E and M1137/-E Mk II box cameras as compatible, in i-CS or standard variants; the i-CS versions are linked above.
Related Products
Related AXIS products, available at Affinitech Store:
- AXIS Lens i-CS 3.9-10 mm F1.5 5MP
- AXIS Lens i-CS 1/1.8-inch 3.9-10 mm F1.5
- AXIS Lens i-CS 9-50 mm F1.5 8MP
Explore More
- Browse all Lenses at Affinitech Store
- See every Network Camera Accessory we carry
- Shop more AXIS products at Affinitech Store
Frequently Asked Questions About AXIS Lens i-CS 3.5-10 mm F1.8
What is the AXIS Lens i-CS 3.5-10 mm F1.8?
A varifocal CS-mount i-CS lens, part number 02638-001, with a 3.5-10 mm focal length and F1.8 aperture for AXIS M1135/-E Mk II and M1137/-E Mk II cameras.
Which cameras does it fit?
Axis lists the AXIS M1135 Mk II, M1135-E Mk II, M1137 Mk II and M1137-E Mk II, and Axis US product data names the i-CS versions of these four.
Can I zoom and focus remotely?
Yes. The lens has three motors for automatic and remote zoom, focus and iris opening.
Is it IR-corrected?
Yes, so you do not need to refocus when the camera switches between day and night mode.
What sensor size does it support?
Sensors up to 1/2.7-inch.
Detailed Specifications
AXIS Lens i-CS 3.5-10 mm F1.8 Specifications
| Specification | Details |
|---|---|
| Product | |
| Model | AXIS Lens i-CS 3.5-10 mm F1.8 |
| Part number | 02638-001 |
| Description | Spare i-CS CS-mount varifocal lens, 3.5-10 mm F1.8, IR-corrected, for sensors up to 1/2.7-inch |
| Key Specifications | |
| Focal length | 3.5-10 mm |
| F-number | F1.8 |
| Iris | i-CS |
| Mount | CS-mount |
| Correction | IR-corrected |
| Image sensor size | Up to 1/2.7-inch |
| Motors | Three: automatic and remote zoom, focus and iris opening |
| Compatibility | |
| Compatible with | AXIS M1135/-E Mk II and M1137/-E Mk II |
| Parts Included | |
| Contents | 1 lens |
| Quantity | 1 |
| Shipping (Axis product data) | |
| Weight | 0.26 lb |
| Dimensions (W x D x H) | 3.35 x 4.72 x 2.36 in |
